- 11 -
Operation
The fur to be cut must be dry and clean. Brush the
fur through to remove any knots.
•
Remove the blade guard  from the cutting
head 1.
• Place the required trimming guide ( - )
with the prongs facing upwards on the cutting
head 1 and thereby press the fl ap of the trim-
ming guide down fi rmly onto the lower metal
edge of the cutting head (see illustration).
• Ensure that the trimming guide has properly
engaged and is secured before starting to cut/
trim the fur.
Note:
It is advisable to fi rst trim a small area so as to test
the individual comb attachments. Start with a comb
attachment for long hair (1/2“
 or 3/8“ )
and, if necessary, use a shorter one. The comb
attachments permit cutting lengths from 3 to 13 mm.
• Switch the appliance on by sliding the On/Off
switch 3 to the position „ON“.
• Slowly run the appliance through the fur against
the direction of hair growth. Hold the appliance
so that the trimming guide is as fl at as possible
against the animal.
• In addition, with the adjustment switch 4 the
cutting length of the cutter head 1 can be
adjusted in steps(up to 2 mm) without having
to exchange the comb attachment. To do this,
slide the adjustment switch 4 backwards to
increase the cutting length in steps. With this the
cutting length of the respectively attached comb
attachment is also increased by up to 2 mm.
Slide the adjustment switch 4 forward again to
reduce the cutting length or to bring the comb
attachment back into its original position.
• Through removal of the individual trimming
guide, i.e. using only the cutting head 1 itself,
you can cut clean contours.
• After use, switch the appliance off by sliding the
On/Off switch 3 to the position „OFF“.
Cleaning and Care
Risk of electric shock!
Before cleaning, remove the plug from the mains
power socket.
NEVER submerse the appliance in water or other
liquids.
• Take the respective trimming guide, if fi tted, off .
•
Using exclusively the cleaning brush , remove
the hairs from the cutting head 1. The cutting
head 1 may not be cleaned with water or
other liquids, except medical alcohol!
• If in regular use, the cutting head 1 should be
oiled occasionally. For this, use the supplied
blade oil
.
• Remove excess oil with a dry cloth.
• Clean the housing with a soft, dry lint-free cloth.
•
Store the appliance in a dry and dust free
location. When it is in storage, place the blade
guard
 on the cutting head 1.
