SilverCrest SWV 300 B2
English - 55
Register WPS
Here, you can connect the dual-band wifi range extender to a WPS-enabled
wireless router in the previously selected 2.4G or 5G band. Click on the Start
PBC button to start WPS. The Power/WPS LED (3) of the dual-band wifi range
extender now flashes for approx. 2 minutes. Within these 2 minutes, please
press the connection button (WPS) on your wireless router. For further details,
please read the operating instructions for your wireless router. The dual-band
wifi range extender then automatically connects to your wireless router and
copies all of the settings. Once the connection has been successfully
established, the 2.4G signal LED (1) or the 5G signal LED (2) lights up. The
dual-band wifi range extender can then be used. You can stop WPS by
clicking on the Stop PBC button.
WPS Status
The current WPS status of the dual-band wifi range extender is displayed here.
The following indicators are possible: Idle – The WPS scan was not started
yet, Started – The WPS scan was started, Failed – The WPS connection
failed, Successful – The WPS connection has been successfully established
and Timeout! – The WPS connection could not be established due to the
timeout.
