■ GB
Introduction
Congratulations!
With your purchase you have decided in favour of a
quality product. Familiarise yourself with the product
before taking it into use. To do this, read the following
operating instructions attentively. Use the product only
as described and only for the specifi ed areas of appli-
cation. Retain these instructions for future reference. In
addition, pass these documents on, together with the
product, to any future owner.
Intended use
The storage set is intended exclusively for the storage
of tools and small parts such as nails, wallplugs, screws
or similar items, in private households. This storage set
is not intended for the storage of fl ammable, toxic or
corrosive liquids. Do not use this storage set in or for
commercial applications, or for purposes for which
it was not intended. A diff erent or additional usage
is considered to be improper use and can lead to
damage. The manufacturer assumes no responsibility
for damage caused by failure to comply with these in-
structions, improper use, incompetent repairs, making
unauthorised modifi cations or for using unapproved
replacement parts.
Safety instructions
For safe interaction with the item pay heed to the
following safety information:
■ When drilling, ensure that damage is not caused
to any electrical cables or other installations, such
as water pipes, in the wall. Drilling into electrical
wires can be fatal!
■ Damaged parts could have sharp edges. There is
also a risk of physical injury! Replace broken or
damaged parts forthwith.
■ Do not burden the wall panels and the boxes too
heavily (see chapter “Technical Data”). This could
lead to irreparable damage.
■ The supplied wallplugs are only suitable for inser-
tion into a concrete or stone wall. It is absolutely
important that you check the suitability of your ma-
sonry before inserting the wallplugs. If you do not,
the wallplugs may not hold and the wall panels
could fall off . If in doubt, consult a professional.
Technical data
Maximum load per wall panel 32 kg
Maximum load - small box 1 kg
Maximum load - medium box 1.5 kg
Maximum load - large box 2 kg
Items supplied
Before taking the item into use, check that all of the
parts are complete/available and free of visible
damage. If the items supplied are not complete, or
damaged due to defective packaging or through
transportation, contact Customer Services (see chap-
ter “Importer/Service”).
▯ 2 x Wall panels (42 x 59 cm)
▯ 14 x Boxes small (red) (11.5 x 10 x 7.3 cm)
▯ 2 x Boxes small (blue) (11.5 x 10 x 7.3 cm)
▯ 8 x Boxes medium (blue) (16.5 x 10 x 7.3 cm)
▯ 4 x Boxes large (yellow) (21.5 x 10 x 7.3 cm)
▯ 10 x Hooks (5 cm)
▯ 1 x Drill and bit holder (16.5 x 5 cm)
▯ 1 x Tool holder (21 x 9.5 cm)
▯ 1 x Ring and open-ended spanner holder
(21.8 x 6.8 cm)
▯ 40 x Screws M5 x 30
▯ 40 x Wallplugs S6
▯ This information sheet
Assembly
Installing the wall panels
▯ Draw a straight line on the wall so as to align the
wall panels with it (see Fig. 1).
▯ Hold the wall panels against the wall and, using
a pointed object, mark the boreholes through the
screw positions.
▯ Drill the holes and insert the supplied plugs into
them.
▯ Screw the wall panels to the wall with at least 10
screws each (see Fig. 2).
Fig. 1
Fig. 2
Mounting the boxes
For one box, you need one free slot in the wall
panels.
▯ Insert the box from above into the open slot such that
both hooks engage in the wall panels (see Fig. 3).
Fig. 3
Securing the hooks
For 10 hooks you need at least two slots. Up to fi ve
hooks can be attached to one slot.
▯ Insert the hook from above into the slot (see Fig. 4).
Securing the drill and bit holder
For the drill and bit holder you need two adjacent slots.
▯ Insert the drill and bit holder from above into the
slots such that both hooks engage in the wall
panel (see Fig. 4).
Securing the tool holder
For the tool holder you need two adjacent slots.
▯ Insert the tool holder from above into the slots
such that both hooks engage in the wall panel
(see Fig. 4).
Securing the ring and open-ended spanner
holder
For the ring and open-ended spanner holder you
need two slots lying adjacent to each other and fi ve
slots one above the other.
▯ Insert the two ring and open-ended spanner hold-
ers from above into the slots such that both hooks
engage in the wall panel (see Fig. 4).
Afb. 3
Bevestiging van de haken
Voor 10 haken heeft u minimaal twee insteekplaatsen
nodig. Er kunnen tot wel 5 haken aan één insteek-
plaats worden bevestigd.
▯ Steek de haken van boven in de insteekplaats
(zie afb. 4).
Bevestiging van de boor en bithouder
Voor de boor en bithouder heeft u twee naast elkaar
gelegen insteekplaatsen nodig.
▯ Steek de boor en bithouder zodanig van boven in
de insteekplaatsen, dat beide haken in de wand-
elementen grijpen (zie afb. 4).
Bevestiging van de gereedschapshouder
Voor de gereedschapshouder heeft u twee naast
elkaar gelegen insteekplaatsen nodig.
▯ Steek de gereedschapshouder zodanig van boven
in de insteekplaatsen, dat beide haken in de
wandelementen grijpen (zie afb. 4).
Bevestiging van de ring- en
steeksleutelhouder
Voor de ring- en steeksleutelhouder heeft u twee
naast elkaar gelegen en vijf boven elkaar gelegen
steekplaatsen nodig.
▯ Steek de twee ring- en steeksleutelhouders zoda-
nig van boven in de insteekplaatsen, dat beide
haken in de wandelementen grijpen (zie afb. 4).
Afb. 4
Reinigen
LET OP
► Gebruik geen schuur- of schoonmaakmiddelen,
omdat deze de delen van kunststof kunnen
beschadigen.
▯ Reinig de wandpanelen en de boxen met een licht
vochtig gemaakte doek. Bij hardnekkig vuil doet u
een mild afwasmiddel op het doek.
Milieurichtlijnen
Voer de opruim- en opberghulp af via een erkend
afvalverwerkingsbedrijf of via uw gemeentereiniging.
Neem de momenteel geldende voorschriften in acht.
Neem in geval van twijfel contact op met de gemeen-
telijke reinigingsdienst.
Voer alle verpakkingsmaterialen op een
milieuvriendelijke manier af.
Importeur/service
KOMPERNASS GMBH
BURGSTRASSE 21
44867 BOCHUM, GERMANY
Tel.: +49 (0) 2327 3018-0
www.kompernass.com
IAN 86237
Fig. 4
Cleaning
IMPORTANT
► Do not use abrasive or aggressive cleaning
agents, these could damage the plastic parts.
▯ Clean the wall panels and the boxes with a lightly
moistened cloth. For stubborn soiling use a mild
detergent on the cloth.
Disposal
Dispose of the appliance via a registered waste dis-
posal fi rm or at your local community waste disposal
facility. Pay heed to the currently applicable regula-
tions. In case of doubt, please contact your waste
disposal centre.
Dispose of all packaging materials in an
environmentally friendly manner.
Importer / Service
KOMPERNASS GMBH
BURGSTRASSE 21
D-44867 BOCHUM
Tel.: +49 (0) 2327 3018-0
www.kompernass.com
IAN 86237
