– 8 –
Aim the remote control at the air conditioner.
Press the ON/OFF button.
When the unit is not in AUTO mode:
Press MODE button.
Move the [ mark] to the (Auto) position.
Temperature adjustment during AUTO
Air temperature adjustment is possible even during automatic operation. There are 6 levels of adjustment possible with the button or the button.
1
AUTO mode operation procedure
■ Automatically selects the operation mode (HEAT, DRY, COOL) depending on the room temperature when switched on.
2
HI POWER TEMP ECONO
AIR FLOW
CANCEL
ON OFF RESERVE
TIMER
TIME ACL
FAN SPEED
ON
MODE
LO
MED
HI
AUTO
TIME
OFF
HI POWER ECONO
AM
Air flow direction adjustment
procedure. Page 10
NOTE
HI POWER TEMP ECONO
AIR FLOW
CANCEL
ON OFF RESERVE
TIMER
TIME ACL
FAN SPEED
ON
MODE
LO
MED
HI
AUTO
TIME
OFF
HI POWER ECONO
AM
WARM
Press the button.
COOL
Press the button.
1
When a change in temperature is desired.
Press the or button.
• If you don’t want the AUTO mode programme, change to
HEAT, DRY or COOL instead of AUTO.
Page 9
AUTO mode can be
operated by simply
pressing the ON/OFF
button.
To stop: Press the ON/OFF button.
■ Each time the button is pushed, the switch over occurs in the following order –6 → –5 → ............ –1 → ±0 → +1 ............ +6.
When +6 is indicatored, even if the button is pushed, the indicator does not change.
■ Each time the button is pushed, the switch over occurs in the following order +6 → +5 → ............ +1 → ±0 → –1 ............ –6.
When –6 is indicatored, even if the button is pushed, the indicator does not change.
• Air is not blowing out during the op-
eration.
Page 18
• Simultaneous automatic operation.
Page 17
• When the included clean filter is in-
stalled the air conditioner will clean
the air during automatic operation.
