Unpack the turntable platter with the upper part of the platter bearing. Remove the
protective security tape from the bearing housing and place this unit carefully over the
spindle mounted in the turntable chassis. Do not use too much pressure for this step
otherwise you will cause damage to the bearing. Caution: pay attention not to place any of
the grease on the acrylic surface of the chassis.
Place the pulley on the motor spindle. The distance between the pulley and the motor
housing should be approx. 1 mm. Tighten the three little screws inside the pulley with the
aluminium screwdriver provided.
1mm
