Kapitel: BIOS-Einstellungen Advanced
Seite 54 Beckhoff New Automation Technology CB3063
5.3.6 SATA Configuration
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Advanced
┌─────────────────────────────────────────────────────────────────┬────────────────────────────────┐
│ SATA Controller(s) [Enabled] │Enable or disable SATA Device. │
│ │ │
│ Serial-ATA (SATA) [Enabled] │ │
│ SATA Test Mode [Disabled] │ │
│ │ │
│ SATA Speed Support [Gen2] │ │
│ SATA ODD Port [No ODD] │ │
│ SATA Mode [AHCI Mode] │ │
│ │ │
│ Serial-ATA Port 0 [Enabled] │ │
│ SATA Port0 HotPlug [Disabled] │ │
│ │ │
│ Serial-ATA Port 1 [Enabled] │────────────────────────────────│
│ SATA Port1 HotPlug [Disabled] │→←: Select Screen │
│ │↑↓: Select Item n │
│ SATA Port0 │Enter: Select │
│ Not Present │+/-: Change Opt. │
│ │F1: General Help │
│ SATA Port1 │F2: Previous Values │
│ Not Present │F3: Optimized Defaults │
│ │F4: Save & Exit │
│ │ESC: Exit │
│ │ │
│ │ │
│ │ │
│ │ │
│ │ │
└─────────────────────────────────────────────────────────────────┴────────────────────────────────┘
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
 Serial-ATA (SATA)
Optionen: Enabled / Disabled
 SATA Test Mode
Optionen: Enabled / Disabled
 SATA Speed Support
Optionen: Gen1 / Gen2
 SATA ODD Port
Optionen: Port0 ODD / Port1 ODD / No ODD
 SATA Mode
Optionen: IDE Mode / AHCI Mode
 Serial-ATA Port X
Optionen: Enabled / Disabled
