JB-Lighting Varyscan P6 575 HMI Benutzerhandbuch
Seite 24
3.2 Set to factory default
3.4 Standalone mode
3.3 DMX addressing
Enter DMX address by means of the keys + and -. Confirm an store by pressing key
ENTER.
To set back the VS P6 to factory setting press key MENU one time.
will be displayed. Press key ENTER to enter FACTORY DEFAULT menu.
Select
and press key ENTER.
will be displayed. Confirm by
pressing key ENTER again. The personal setting of the VS P6 will be set back to
factory default.
FACTORY
DEFAULT
LOAD DEFAULTS
SURE
A sequence consisting of preprogrammed cues can be recalled by means of the
Standalone mode. The sequence will run as a loop. Cues can be entered in two
different ways. The first way is to program every feature by means of the key of the
units own control panel.
The second way is to program the cues by means of a connected DMX control
console and to store them onboard of the VS P6
Enter DMX values by means of the control panels keys:
Recall standalone mode:
Press key MENU first. Then press key + five times (see page 24).
will be displayed. Confirm by pressing key ENTER.
will be
shown. Confirm again by pressing ENTER. After this second confirmation the display
will show: MODIFY 1/1. Now recall the modify menu by pressing key ENTER. The
modify menu enables access to all parameters of the unit. Use key + and - to recall
the desired parameter. Confirm choice by pressing ENTER. Enter DMX values by
means of the keys +and -. Store DMX values by pressing key ENTER. To escape
press key MENU.
STANDALONE
STEPS
STEP NR. 1/1
Add one step to the sequence:
Press key + untill MENU
is shown. Confirm by pressing key ENTER.
will be displayed. Confirm by pressing key ENTER again. A new step will be added to
the sequence. The DMX values of the last step will be automatically copied to the new
step. To older DMX values enter modify menu and proceed like describe in chapter:
Enter DMX values by means of the control panel keys.
INSERT
SURE?
Delete one step of a sequence:
Recall the Standalone menu.
must be shown on the display.
Confirm by pressing key ENTER.
will be displayed. Use keys + and -
to recall the desired step. Confirm selection by pressing key ENTER. Select menu
DELETE by pressing key +. Confirm the selection of the step by pressing key ENTER.
STANDALONE STEPS
STEP NR: 1/X
SURE? will be displayed. Now confirm again by pressing key ENTER and the selected
step will be deleted.
25
