Varyscan 3 Special 250MSD
16
JB-lighting Lichtanlagentechnik GmbH Sallersteigweg 15 D-89134 Blaustein Tel. ++49-7304-9617-0
The Varyscan 3 is equipped with one colourwheel with 10 colours, one multicolour effect
plus white. 12 gobos, six of them interchangeable. Rainbow effect in different speeds,
effect wheel with prism, floodfilter, daylight filter and conversion filter, dimmer and high
speed shutter. In addition the six interchangeable gobos of Varyscan 3 Special
are rotatable and indexable.
Plus
weight : 12 kg
power supply: 230V 50Hz
current consuption
without compensation: 3.2A
with compesation: 1.8A
lamp: PHILIPS 250MSD
OSRAM 250HSD
max.
ambient temperature:
50°C
1.3 Technical Data
244 146
DMX connector
DIP switch
mains connection
fuse 5AT
322 172
500 535
fan
1. Indroduction
1.1 General Remarks
1.2 Unpacking
Open the top of the box and remove the unit with the inlays. Remove the
inlays from the Varyscan.
For any damage occuring during transport, report to the transport company
immediately.
