.ﻝﻔﺳﻷﺍ ﻲﻓ ﺩﻭﺟﻭﻣﻟﺍ (TAP (22 ﺭﺯﺑ ﻁﺑﺿﻠﻟ ﻝﺑﺎﻗ ﺕﻗﻭ ﻊﻣ ﻰﻠﻋﻷﺍ ﻲﻓ ﺎﻧﻫ STEREO DELAY ـﻛ - STEREO TAP DELAY .9 ﺹ
.[16] 90% ﻰﻟﺇ [1] 5% ﻥﻣ (feedback) ﺭﺍﺭﻛﺗﻟﺍ ﺔﻳﻣﻛ ﻥﻣ ﺕﺎﻌﻳﻭﻧﺗﻟﺍ ﺭﻳﻐﺗ
.ﻝﻔﺳﻷﺍ ﻲﻓ ﺩﻭﺟﻭﻣﻟﺍ (22) ـ TAP ﺭﺯﺑ ﻁﺑﺿﻠﻟ ﻝﺑﺎﻗ ﺕﻗﻭ ﻊﻣ ﻲﻁﻣﻧ eco monoﻥﺇ - MONO TAP DELAY .10 ﺹ
.[16] 75% ﻰﻟﺇ [1] 0% ﻥﻣ (feedback) ﺭﺍﺭﻛﺗﻟﺍ ﺔﻳﻣﻛ ﻥﻣ ﺕﺎﻌﻳﻭﻧﺗﻟﺍ ﺭﻳﻐﺗ
.ﻲﺗﻭﺻﻟﺍﻭ ﻲﺋﺎﺑﺭﻬﻛﻟﺍ ﺱﺎﺑﻟﺍﻭ ﺭﺎﺗﻳﺟﻟﺍ ﺔﻳﻭﻘﺗﻟ ﺍﺩﺟ ﺏﺳﺎﻧﻣ .ﺩﺩﺭﺗﻟﺍ ﻥﻣ ﺔﻳﺭﻳﺛﺃﻭ ﺔﺳﻠﺳ ﺕﺎﺟﻭﻣﺗﻟ ﻡﻣﺻﻣﻭ ﻝﺩﻌﻣ ﻲﻁﻣﻧ ﺭﻳﺛﺄﺗ - CHORUS .11 ﺹ
.ﺱﺍﺭﻭﻛﻟﺍﻭ ﺕﺎﻋﻭﻣﺟﻣﻟﺍ ﺔﺻﺎﺧﻭ ﺕﺍﻭﺻﻷﺍ ﺔﻳﻭﻘﺗ ﺎﺿﻳﺃ
.[16] ﺯﺗﺭﻫ 5 ﻰﻟﺇ [1] ﺯﺗﺭﻫ 0.5 ﻥﻣ ﺕﺎﺟﻭﻣﻟﺍ ﺩﺩﺭﺗ ﻥﻣ ﺕﺎﻌﻳﻭﻧﺗﻟﺍ ﺩﻳﺯﺗ
.ﻲﻋﺎﻘﻳﻹﺍﻭ ﺩﺭﻔﻧﻣﻟﺍ ،ﻲﺗﻭﺻﻟﺍﻭ ﻲﺋﺎﺑﺭﻬﻛﻟﺍ ﺭﺎﻳﺗﺟﻟﺍ ﻰﻠﻋ ﺔﺻﺎﺧ ﻡﺩﺧﺗﺳُﻳ .ﺩﺩﺭﺗﻣ ﻱﻭﻗ ﺭﻳﺛﺄﺗﺑ ﺯﻳﻣﺗﻳ ﻝﺩﻌﻣ ﻲﻁﻣﻧ ﺭﻳﺛﺄﺗ - FLANGER .12 ﺹ
.[16] ﺯﺗﺭﻫ 3 ﻰﻟﺇ [1] ﺯﺗﺭﻫ 0.2 ﻥﻣ ﺕﺎﺟﻭﻣﻟﺍ ﺩﺩﺭﺗ ﻥﻣ ﺕﺎﻌﻳﻭﻧﺗﻟﺍ ﺩﻳﺯﺗ
.ﺎﻳﻭﺳ ﺎﻣﻬﻧﻳﺑ ﻊﻣﺟﻟﺍﻭ ﻭﻳﺭﺗﺳﻻﺍﻭ ﺕﻭﺻﻟﺍ ﺭﻳﺧﺄﺗﻟ ﻲﻁﻣﻧ ﻯﺩﺻ - REVERB+DELAY 1 .13 ﺹ
.[16] ﺭﻳﺻﻗ ﻰﻟﺇ [1] ﻝﻳﻭﻁ ﻥﻣ ﻝﻼﺣﻣﺿﻻﺍ ﺕﻗﻭ ﻥﻣ ﺕﺎﻳﻋﻭﻧﺗﻟﺍ ﺭﻳﻐﺗ
.ﺎﻳﻭﺳ ﺎﻣﻬﻧﻳﺑ ﻊﻣﺟﻟﺍﻭ ﻭﻧﻭﻣﻟﺍﻭ ﺕﻭﺻﻟﺍ ﺭﻳﺧﺄﺗﻟ ﻲﻁﻣﻧ ﻯﺩﺻ - REVERB+DELAY 2 .14 ﺹ
.[16] ﺭﻳﺻﻗ ﻰﻟﺇ [1] ﻝﻳﻭﻁ ﻥﻣ ﻝﻼﺣﻣﺿﻻﺍ ﺕﻗﻭ ﻥﻣ ﺕﺎﻳﻋﻭﻧﺗﻟﺍ ﺭﻳﻐﺗ
.ﺎﻳﻭﺳ ﺎﻣﻬﻧﻳﺑ ﻊﻣﺟﻟﺍﻭ mono TAPﻭ hall ﺭﻳﺧﺄﺗﻟ ﻲﻁﻣﻧ ﻯﺩﺻ - REVERB+TAP DELAY .15 ﺹ
ﻝﻔﺳﻷﺎﺑ ﺩﻭﺟﻭﻣﻟﺍ (TAP (22 ﺭﺯﺑ ﻁﺑﺿﻠﻟ ﻝﺑﺎﻗ mono ﺭﻳﺧﺄﺗ ﺕﻗﻭ
.[1-16] 75% ﻰﻟﺇ 0% ﻥﻣ (feedback) ﺭﺍﺭﻛﺗﻟﺍ ﺔﻳﻣﻛﻭ ،[16] ﺭﻳﺻﻗ ﻰﻟﺇ [1] ﻝﻳﻭﻁ ﻥﻣ ﻝﻼﺣﻣﺿﻻﺍ ﺕﻗﻭ ﺕﺎﻌﻳﻭﻧﺗﻟﺍ ﺭﻳﻐﺗ
.ﺎﻳﻭﺳ ﺎﻣﻬﻧﻳﺑ ﻊﻣﺟُﻳ ﺱﺍﺭﻭﻛﻟﺍ ﺭﻳﺛﺄﺗﻭ ﺕﻭﺻﻠﻟ ﻲﻁﻣﻧ ﻯﺩﺻ - REV+CHORUS .16 ﺹ
.[1-16] ﺯﺗﺭﻫ 5 ﻰﻟﺇ ﺯﺗﺭﻫ 0.5 ﻥﻣ ﺕﺎﺟﻭﻣﻟﺍ ﺩﺩﺭﺗ ﺩﻳﺯﺗﻭ ،[16] ﺭﻳﺻﻗ ﻰﻟﺇ [1] ﻝﻳﻭﻁ ﻥﻣ ﻝﻼﺣﻣﺿﻻﺍ ﺕﻗﻭ ﺕﺎﻌﻳﻭﻧﺗﻟﺍ ﺭﻳﻐﺗ
(ﺕﻗﻭﻟﺍ ﻁﺑﺿ ﺭﺯ) TAP .22
ﺏﺳﺣ ،ﺏﻭﻠﻁﻣﻟﺍ ﺭﺍﺭﻛﺗﻟﺍ ﺕﻗﻭ ﻁﺑﺿ ﻥﻛﻣﻣﻟﺍ ﻥﻣ ﻥﻳﺗﺭﻣ ﻝﻗﻷﺍ ﻰﻠﻋ ﺭﺯﻟﺍ ﺍﺫﻫ ﻰﻠﻋ ﻁﻐﺿﻟﺎﺑ ،(15 ،10 ،9 ﺹ) "TAP DELAY" ﺭﻳﺛﺄﺗ ﺩﻳﺩﺣﺗ ﺩﻧﻋ
.ﻲﻘﻳﺳﻭﻣﻟﺍ ﻉﺎﻘﻳﻹﺍ
(ﺔﻣﻘﻟﺍ ﻑﺷﺎﻛ) PEAK .23
.PROFEX ﺞﻟﺎﻌﻣﻠﻟ A/D ﻝﻭﺣﻣﻟﺍ ﻊﺑﺷﺗ ﻥﻣ ﺭﻳﺛﺄﺗﻟﺍ ﻝﺧﺩ ﺓﺭﺎﺷﺇ ﺏﺭﺗﻘﺗ ﺎﻣﺩﻧﻋ ﺔﻣﻘﻟﺍ LED ﺽﻣﻭﻳ
.(AUX2 (Mi12) / AUX1 (Mi10 ﻡﻛﺣﺗ ﺽﻔﺧﺑ ﻝﺧﺩﻟﺍ ﻯﻭﺗﺳﻣ ﺽﻔﺧ LED PEAK ﺽﻳﻣﻭ ﺔﻟﺎﺣ ﻲﻓ :ﻡﺎﻫ
(ﺭﻳﺛﺄﺗﻟﺍ ﻯﻭﺗﺳﻣ) FX LEVEL .24
.MAIN MIX ﺝﺭﺧ ﻰﻟﺇ ﺔﻠﺳﺭﻣﻟﺍ ﻲﻠﺧﺍﺩﻟﺍ ﺭﻳﺛﺄﺗﻟﺍ ﺓﺭﺎﺷﺇ ﻯﻭﺗﺳﻣ ﻡﻅﻧﻳ
(Mi12 ﻝﺟﺃ ﻥﻣ ﻁﻘﻓ AUX 1 ﻰﻠﻋ ﺭﻳﺛﺄﺗﻟﺍ ﻯﻭﺗﺳﻣ) FX TO AUX1 .25
.AUX1 ﺝﺭﺧ ﻰﻟﺇ ﺔﻠﺳﺭﻣﻟﺍ ﻲﻠﺧﺍﺩﻟﺍ ﺭﻳﺛﺄﺗﻟﺍ ﺓﺭﺎﺷﺇ ﻯﻭﺗﺳﻣ ﻡﻅﻧﻳ
(rca stereo ﻝﺧﺩ) 2TRK INPUT .26
ﺝﺭﺧ ،CD/DVD ﺉﺭﺎﻗ ﻭﺃ MP3 ﺉﺭﺎﻗ ،ﻱﺭﻅﺎﻧﺗﻟﺍ ﻝﺟﺳﻣﻟﺍ ﻝﺛﻣ ﻁﺧ ﺭﺩﺻﻣ ﺝﺭﺧﻣ ﻝﻳﺻﻭﺗﻟ RCA ﺕﻼﺻﻭﻣ ﻊﻣ ﺔﻧﺯﺍﻭﺗﻣﻟﺍ ﺭﻳﻏ ﻝﺧﺍﺩﻣﻟﺍ ﻩﺫﻫ ﻡﺩﺧﺗﺳُﺗ
.ﺭﺗﻭﻳﺑﻣﻛﻟ ﻲﺗﻭﺻ
(rca stereo ﺝﺭﺧ) 2TRK OUTPUT .27
.ﺕﻭﺻ ﻝﺧﺩﺑ ﺭﺗﻭﻳﺑﻣﻛ ﻭﺃ ﻱﺭﻅﺎﻧﺗ ﺕﻳﺳﺎﻛ ﻝﺟﺳﻣ ﻝﺛﻣ ﻝﺟﺳﻣ ﻰﻟﺇ MAIN MIX ﺝﺭﺧ ﺓﺭﺎﺷﺇ ﻝﺎﺳﺭﻹ ﺔﻧﺯﺍﻭﺗﻣﻟﺍ ﺭﻳﻏ RCA ﺕﻼﺻﻭﻣ ﻡﺩﺧﺗﺳﺍ
(ﻯﻭﺗﺳﻣﻟﺍ ﻲﻓ ﻡﻛﺣﺗﻟﺍ) 2TRK IN LEVEL .28
.2TRK INPUT ﻝﺧﺩﻣ ﻯﻭﺗﺳﻣ ﻁﺑﺿﻳ
(ﺭﺯ) TO MIX / TO PHONES .29
.ﻁﻘﻓ C.ROOM/PHONES ﻰﻟﺇ ﻭﺃ MAIN MIX ﻰﻟﺇ 2TRK ﻝﺧﺩﻣ ﻥﻣ ﺓﺭﺩﺎﺻﻟﺍ ﺓﺭﺎﺷﻹﺍ ﻪﻳﺟﻭﺗﻟ ﺭﺯﻟﺍ ﺍﺫﻫ ﻡﺩﺧﺗﺳﺍ
(ﺔﻧﺯﺍﻭﺗﻣ jack ﺝﺭﺎﺧﻣ) MAIN MIX L & R .30
.MAIN MIX ﻭﻳﺭﺗﺳﺍ ﻝﻗﺎﻧﻠﻟ ﻥﺯﺍﻭﺗﻣ ﻁﺧ ﻯﻭﺗﺳﻣ ﻱﺫ ﺎﺟﺭﺧﻣ (+4dBu) ـ JACK ﺕﻼﺻﻭﻣ ﻲﻁﻌﺗ
ﻦﻜﻤﻳ ،ﻚﻟﺫ ﻰﻠﻋ ءﺎﻨﺑﻭ .phantom power ﻂﻴﺸﻨﺗ ﻥﻭﺪﺑ ﻭﺃ ﻊﻣ ﻥﺯﺍﻮﺘﻣ ﻂﺧ ﻰﻠﻋ ﺓﺭﺎﺷﺇ ﻝﺎﺳﺭﺇ ﻊﻴﻄﺘﺴﻳ ﺎﻴﻠﻌﻓ ﻥﺯﺍﻮﺘﻣ ﺝﺮﺨﻣ ﻦﻋ ﺓﺭﺎﺒﻋ MAIN OUT ﻥﺇ :ﺔﻈﺣﻼﻣ
.ﻲﺴﻴﺋﺮﻟﺍ ﻁﻼﺨﻟﺍ ﻰﻟﺇ ﺓﺭﺎﺷﺇ ﻝﺎﺳﺭﻹ DI ﻕﻭﺪﻨﺻ + ﻁﻼﺧ ﺔﻔﻴﻟﻮﺘﻛ Mi10 e Mi12 ﻡﺍﺪﺨﺘﺳﺍ
(MIX ﺝﺭﺧ ﻯﻭﺗﺳﻣ) MAIN MIX FADER .31
ﻩﺩﻭﺩﺣ ﻲﻓ fader ـﻟﺍ ﻥﻭﻛﻳ ﺎﻣﺩﻧﻋ .2TRK OUT ﺝﺭﺧﻣﻭ ،MAIN MIX ﺝﺭﺧﻣ ﻝﺑﻗ ﺎﻣﺎﻣﺗ ﺝﺭﺧﻣﻟﺍ ﻯﻭﺗﺳﻣ ﻲﻓ MAIN MIX FADER ﻡﻛﺣﺗﻳ
ـﻟﺍ ﺍﺫﻫ ﻥﻳﻳﻌﺗ ﺓﺩﺎﻋ ﻡﺗﻳ .ﻝﺑﻳﺳﻳﺩ ﺓﺩﺣﻭ +4 ـﺑ ﻥﺯﺍﻭﺗﻣ ﻝﺑﻛ ﻰﻠﻋ ﺝﺭﺧﻠﻟ ﻲﻣﺳﻻﺍ ﻯﻭﺗﺳﻣﻟﺍ ﻥﺃ ﻰﻠﻋ ﻝﺩﺗ "0" ﺔﻁﻘﻧ ﺎﻣﻧﻳﺑ ،ﺎﺋﻔﻁﻧﻣ MAIN MIX ﺢﺑﺻﻳ ،ﺎﻳﻧﺩﻟﺍ
.ﺓﺭﻭﺭﺿﻟﺍ ﺔﻟﺎﺣ ﻲﻓ ﺔﻋﺭﺳﺑ ﺕﻭﺻﻟﺍ ﺔﻣﻭﻅﻧﻣ ﺕﺎﻛﺳﺇ ﻭﺃ ﺕﺎﻳﻧﻏﻷﺍ ﻝﻳﻠﻅﺗﻟ ﺎﺿﻳﺃ ﻪﻣﺍﺩﺧﺗﺳﺍ ﻥﻛﻣﻳ ﻥﻛﻟﻭ ،ﺎﻧﻫ ﻙﺭﺗﻳﻭ ،"0" ﻥﻣ ﺎﺑﻳﺭﻗ fader
(jack ﺝﺭﺧ) C.ROOM L & R .32
ﻥﻣ ﺝﺭﺧﻣﻟﺍ ﺞﻣﺎﻧﺭﺑ ﻲﻓ ﻲﻠﻳﻣﻛﺗ ﺝﺭﺧﻣﻛ ﺎﺿﻳﺃﻭ ﺔﻠﺻﻔﻧﻣ ﺔﻘﻳﺭﻁﺑ ﻡﻛﺣﺗﻠﻟ ﻪﻣﺍﺩﺧﺗﺳﺍ ﻥﻛﻣﻳ ﻁﺧ ﻯﻭﺗﺳﻣﻟ ﻥﺯﺍﻭﺗﻣ ﺭﻳﻏ ﺝﺭﺧﻣ ﻩﺫﻫ JACK ﺕﻼﺻﻭﻣ ﻲﻁﻌﺗ
.MAIN MIX
(ﺱﺃﺭﻟﺍ ﺕﺎﻋﺎﻣﺳﻟ jack stereo per ﺝﺭﺧﻣ) PHONES .33
.ﻡﻭﺃ 32 ﻥﻋ ﻝﻘﺗ ﻻ ﺔﻗﻭﺎﻌﻣ ﻰﻠﻋ ﺱﺃﺭﻟﺍ ﺕﺎﻋﺎﻣﺳ ﻱﻭﺗﺣﺗ ﻥﺃ ﺏﺟﻳ :ﺱﺃﺭﻟﺍ ﺕﺎﻋﺎﻣﺳ ﺝﺭﺧﻣﻟ STEREO JACK ﻝﺻﻭﻣ
(c.roomﻭ ﺱﺃﺭﻟﺍ ﺕﺎﻋﺎﻣﺳ ﺝﺭﺧ ﻯﻭﺗﺳﻣ) C.ROOM/PHONES LEVEL .34
.ﺎﻬﺴﻔﻧ ﻲﻫ ﻦﻴﺟﺮﺨﻤﻟﺍ ﻦﻳﺬﻫ ﺓﺭﺎﺷﺇ :ﺔﻈﺣﻼﻣ
.PHONESﻭ CONTROL ROOM ﺱﺑﺎﻗ ﺝﺭﺧﻣ ﻯﻭﺗﺳﻣ ﻡﻅﻧﻳ
(Mi12 ﻰﻠﻋ ﻁﻘﻓ jack ﺝﺭﺧ) AUX 1 OUT .35
