ﻝﺧﺩ ﻝﻳﺻﻭﺗﻟ ﺓﺩﺎﻋ ﻡﺩﺧﺗﺳُﻳ .ﺓﺩﺭﻔﻧﻣﻟﺍ ﺕﺍﻭﻧﻘﻠﻟ AUX 1 ﻡﻳﻠﺳﺗ ﻝﻛ ﻉﻭﻣﺟﻣ ﻥﻣ ﺔﻧﻭﻛﻣ ﺔﻧﺯﺍﻭﺗﻣ ﺭﻳﻏ ﻁﺧ ﺓﺭﺎﺷﺇ ﺝﺭﺎﺧﻟﺍ ﻰﻟﺇ ﻝﺻﻭﻣﻟﺍ ﺱﺑﺎﻘﻟﺍ ﺍﺫﻫ ﻝﺳﺭﻳ
.ﺓﺎﻧﻘﻟﺍ ﻯﻭﺗﺳﻣ ﻲﻓ ﻡﻛﺣﺗـﻟﺍ ﻊﺿﻭ ﻰﻠﻋ ﺩﻣﺗﻌﺗ ﺎﻬﻧﺃ ﻲﻧﻌﻳ ﺎﻣﻣ ،pre-fader ﻲﻫ ﺓﺭﺎﺷﻹﺍ ﻩﺫﻫ .ﻥﻳﺗﻣﺧﺿﻣ ﺡﺭﺳﻣ ﺔﺷﺎﺷﻟ ﻭﺃ ﻲﺟﺭﺎﺧ ﺭﻳﺛﺄﺗ
(jack ﺝﺭﺧ) AUX 1 (Mi10) / AUX2 (Mi12) OUT .36
.ﺓﺩﺭﻔﻧﻣﻟﺍ ﺕﺍﻭﻧﻘﻠﻟ (AUX 1 (Mi10) / AUX 2 (Mi12 ﻡﻳﻠﺳﺗ ﻝﻛ ﻉﻭﻣﺟﻣ ﻥﻣ ﺔﻧﻭﻛﻣ ﺔﻧﺯﺍﻭﺗﻣ ﺭﻳﻏ ﻁﺧ ﺓﺭﺎﺷﺇ ﺝﺭﺎﺧﻟﺍ ﻰﻟﺇ ﻝﺻﻭﻣﻟﺍ ﺱﺑﺎﻘﻟﺍ ﺍﺫﻫ ﻝﺳﺭﻳ
.ﺓﺎﻧﻘﻟﺍ ﻯﻭﺗﺳﻣ ﻲﻓ ﻡﻛﺣﺗﻟﺍ ﻊﺿﻭ ﻰﻠﻋ (post-fader) ﺓﺭﺎﺷﻹﺍ ﻩﺫﻫ ﺩﻣﺗﻌﺗ .ﻥﻳﺗﻣﺧﺿﻣ ﺡﺭﺳﻣ ﺔﺷﺎﺷﻟ ﻭﺃ ﻲﺟﺭﺎﺧ ﺭﻳﺛﺄﺗ ﻝﺧﺩﻣ ﻝﻳﺻﻭﺗﻟ ﺓﺩﺎﻋ ﻡﺩﺧﺗﺳُﻳ
(ﻯﻭﺗﺳﻣﻟﺍ ﺕﺍﺭﺷﺅﻣ) L & R LEVEL METERS .37
:ﺔﻋﻭﻧﺗﻣ ﺔﻳﻠﻳﻐﺷﺗ ﺕﺎﻳﻭﺗﺳﻣ ﻰﻠﻋ ﻝﺩﺗ ،ﻥﺍﻭﻟﻷﺍ ﻥﻣ ﺢﻳﺑﺎﺻﻣ ﺔﻌﺑﺭﺃ ﻥﻣ ﻥﻳﺩﻭﻣﻋ ﻥﻣ ﻯﻭﺗﺳﻣﻟﺍ ﺕﺍﺭﺷﺅﻣ ﻝﻛﺷﺗﺗ
(ﺔﻣﻗ ﻝﺑﻳﺳﻳﺩ 0 ﻰﻟﺇ -20 ﻥﻣ) ﺓﺭﺎﺷﻹ ﻱﺩﺎﻋ ﻲﻠﻳﻐﺷﺗ ﻯﻭﺗﺳﻣ = ﺭﺿﺧﺃ •
(ﺔﻣﻗ ﻝﺑﻳﺳﻳﺩ +6 ﻰﻟﺇ 0 ﻥﻣ) ﺓﺭﺎﺷﻹ ﻱﺩﺎﻋ ﻲﻠﻳﻐﺷﺗ ﻯﻭﺗﺳﻣ = ﺭﻔﺻﺃ •
.(CLIP +20CLIP +20dBpeak ﻯﻭﺗﺳﻣ ﻥﻣ ﺏﻳﺭﻗ) ﻱﺩﺎﻋ ﺓﺭﺎﺷﺇ ﻯﻭﺗﺳﻣ = ﺭﻣﺣﺃ •
phantom ﺔﻳﺫﻐﺗ ﺡﺎﺗﻔﻣ +48V .38
ﻑﺛﻛﻣﺑ ﻝﻣﻌﺗ ﻲﺗﻟﺍ ﺔﻳﻧﻬﻣﻟﺍ ﺕﺎﻧﻭﻓﻭﺭﻛﻳﻣﻟﺍ ﻥﻣ ﻰﻣﻅﻌﻟﺍ ﺔﻳﺑﻟﺎﻐﻟﺍ ﺝﺎﺗﺣﺗ .MIC ﺕﺎﻧﻭﻓﻭﺭﻛﻳﻣﻟﺍ ﻝﺧﺩ ﻲﻓ phantom ﺔﻳﺫﻐﺗ ﻁﻳﺷﻧﺗ ﻲﻐﻠﻳﻭ ﺡﺎﺗﻔﻣﻟﺍ ﺍﺫﻫ ﻁﺷﻧﻳ
ﺕﺎﻧﻭﻓﻭﺭﻛﻳﻣﻟﺍ ﺝﺎﺗﺣﺗ ﻻ .XLR ﻝﺻﻭﻣﻠﻟ 3ﻭ 2 ﻥﻳﻓﺭﻁ ﻰﻠﻋ ﻥﻭﻓﻭﺭﻛﻳﻣﻟﺍ ﻰﻟﺇ ﻝﻭﻣﺣﻣ ﺭﻣﺗﺳﻣ ﺭﺎﻳﺗﺑ ﺩﻬﺟ ﻥﻋ ﺓﺭﺎﺑﻋ ﻲﻫﻭ ،phantom ﺔﻳﺫﻐﺗ ﻰﻟﺇ
ﻊﺟﺍﺭ .ﻝﻳﻐﺷﺗﻟﺍ ﺩﻌﺑ ﺎﻬﻟﺎﺧﺩﺇ ﺩﻧﻋ ﺔﻳﻛﻳﻣﺎﻧﻳﺩﻟﺍ ﺕﺎﻧﻭﻓﻭﺭﻛﻳﻣﻠﻟ ﺭﺭﺿ ﻱﺃ phantom ﺔﻳﺫﻐﺗ ﺏﺑﺳﺗ ﻻ ﻥﺃ ﺏﺟﻳ ،ﻙﻟﺫ ﻊﻣﻭ ،phantom ﺔﻳﺫﻐﺗ ﻰﻟﺇ ﺔﻳﻛﻳﻣﺎﻧﻳﺩﻟﺍ
.ﻻ ﻡﺃ ﻥﻭﻓﻭﺭﻛﻳﻣﻟﺍ ﻲﻓ ﺎﻔﻠﺗ ﺏﺑﺳﺗ ﻥﺃ ﻥﻛﻣﻳ phantom ﺔﻳﺫﻐﺗ ﻥﺃ ﺩﻛﺄﺗﻠﻟ ﻥﻭﻓﻭﺭﻛﻳﻣﻟﺍ ﻝﻳﻟﺩ
(ﺊﻔﻁﻧﻣ/ءﻲﺿﻣ ﺭﺷﺅﻣ) ON led .39
.ﻝﻣﻌﻳ ﻁﻼﺧﻟﺍ ﻥﺃ ﻰﻠﻋ ﻝﺩﻳ
ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ ﺔﻳﺫﻐﺗﻟﺍ ﺱﺑﻘﻣ ~18V .40
.ﺔﻳﺋﺎﺑﺭﻬﻛﻟﺍ ﺔﻛﺑﺷﻟﺍ ﺱﺑﻘﻣ ﻲﻓ ﺩﺍﺩﻣﻹﺍ ﺓﺩﺣﻭ ﻝﺎﺧﺩﺇ ﻝﺑﻗ ﻝﺻﻭﻣﻟﺍ ﺍﺫﻫ ﺎﻣﺋﺍﺩ ﻝﺻ .ﺔﻳﺟﺭﺎﺧﻟﺍ ﺔﻗﺎﻁﻟﺍ ﺩﺍﺩﻣﺇ ﺓﺩﺣﻭ ﻝﺧﺩﻣ ﺱﺑﻘﻣ
ﻝﻳﻐﺷﺗﻟﺍ ﺡﺎﺗﻔﻣ POWER .41
ﻝﻳﻐﺷﺗ ﺩﻧﻋ ﺎﻳﻧﺩﻟﺍ ﺎﻫﺩﻭﺩﺣ ﻲﻓ ﺝﺭﺧﻟﺍ ﺽﺑﺎﻘﻣ ﻊﻳﻣﺟ ﻥﺃ ﺩﻛﺄﺗ .ﺍﺩﺩﺟﻣ ﺔﻳﺫﻐﺗﻟﺍ ﺊﻔﻁﻧﺗ ﻑﻭﺳ ﻪﻣﺍﺩﺧﺗﺳﺎﺑﻭ ،ﻁﻼﺧﻟﺍ ﺔﻳﺫﻐﺗ ﻡﺗﺗ ﻑﻭﺳﻓ ﺡﺎﺗﻔﻣﻟﺍ ﺍﺫﻫ ﻡﺍﺩﺧﺗﺳﺍ ﺩﻧﻋ
.ﻁﻼﺧﻟﺍ ﻝﺎﻁﺑﺇ ﻭﺃ
ﺞﺗﻧﻣﻟﺍ ﻖﺻﻠﻣ .42
.ﻝﺳﻠﺳﻣﻟﺍ ﻡﻗﺭﻟﺍﻭ ،ﻙﻼﻬﺗﺳﻻﺍﻭ ،ﺔﻳﺫﻐﺗﻟﺍ ﺩﻬﺟﻭ ﻝﻳﺩﻭﻣﻟﺍﻭ ،ﻁﻼﺧﻟﺎﺑ ﺔﺻﺎﺧﻟﺍ ﺔﻣﻬﻣﻟﺍ ﺕﺎﻣﻭﻠﻌﻣﻟﺍ ﻊﻳﻣﺟ ﻖﺻﻠﻣﻟﺍ ﺍﺫﻫ ﻰﻠﻋ ﺢﺿﻭُﺗ
