outdoor 80
12
Technical data
Guarantee
The guarantee period is 60
months from the date of purchase
Your dealer should be your first
contact if you need service.
If he can't give you the help you
need, send your speaker system
carriage free and without any
accessories to your national Sales
Office. Please supply a complete
description of the problem and a
full return postal address.
Audio data
Frequency range:
52 Hz - 32 kHz
(IEC)
Power capacity:
80 / 110 Watt
Impedance:
6 Ohm
Nominal sound pressure: 87 dB/ 2.83 V/ 1m
Cross over frequency:
3.5 kHz
Rec. Amplifier power:
20 – 100 W (undistorted signal)
Temperature range:
-10° to +70° C
Overload protection:
Reversible, seperated for woofer and tweeter
Components:
1 x 133 mm woofer (aluminium)
1 x 21 mm dome tweeter (aluminium)
Dimensions
Speaker without bracket: 185 x 250 x 165 mm (W x H x D)
Depth with bracket:
190 mm / 7,5 inch
Colour: White
Weight :
2,8 kg /6.2 lb
(each speaker)
E & OE
Product subject to technical modification
