Section 3 · Powador-LOG
3.6 Web server
The graphics are transferred via the HTTP server of the Powador-LOG. The information is
displayed in an RSS feed or a graphic optimised for iPhone/iPod Touch.
3.6.1 Retrieving the graphics
The RSS feed can be displayed using a standard web browser. The graphics optimised for
the iPhone/iPod Touch are displayed using the integrated browser of the iPhone/iPod.
3.6.2 User interface
The user interface of the Powador-LOG can be retrieved using a web browser. With the user
interface, you can confi gure the graphics and set the date and time of the Powador-LOG.
Ethernet connection example
IP address of the Powador-LOG: 192.168.106.200
PC IP address: 192.168.106.250
3.6.2.1 Opening the user interface
•
Open a browser on your PC or your iPhone/iPod Touch.
• Enter “http://192.168.106.200:34666/” in the address bar of the browser (with
Ethernet) or enter “http://192.168.37.1:34666/” in the iPhone/iPod Touch (with
WLAN).
ENGLISH
N OT I C E
The Powador-LOG must be addressed using the correct IP address and subnet mask.
The standard IP address via Ethernet is 192.168.106.200 with the subnet mask
255.255.255.0. This means that the Powador-LOG can be addressed by a PC with the
IP address 192.168.106.xxx and the subnet mask 255.255.255.0. “xxx” stands for any
number between 1 and 254, although the number 200 is already assigned to the
Powador-LOG.
