10 GB/IE/CY
Q Replacing the
sharpening stone
RISK OF INJURY! Before you
carry out any work on the device, always pull the
mains plug out of the mains socket. Replace the
sharpening stone if it is worn out or damaged
(deteriorating, irregular sharpening performance,
broken stone). A Phillips screwdriver is required for
this step.
Screw the four screws 3 out of the sharpening
head cover 2 and remove the cover 2 , refer
to Fig. A.
Take out the sharpening stone 5 .
Clamp the sharpening stone 5 in a vice. Re-
lease the threaded connection 7 , which holds
the sharpening stone 5 on to the sharpening
stone holder 9 , using a 20 mm open spanner,
see Fig. B.
NOTE! LEFT-HAND THREAD - TO RELEASE
TURN IT CLOCKWISE!
Remove the metal washer
8 .
Mount the new sharpening stone, with its flat-
tened edge facing downwards, on to the
sharpening holder
9 and reinsert the metal
washer 8 .
Clamp the sharpening stone 5 again in a vice
and tighten the threaded connection 7 using
a 20 mm open spanner.
NOTE! LEFT-HAND THREAD - TO TIGHTEN
TURN IT ANTICLOCKWISE!
Ensure that the spring 6 is inserted into the
device in accordance with Fig. D and insert the
sharpening stone back into the device. Turn the
sharpening stone until it goes precisely back
into place, as shown in Fig. A, otherwise the
sharpening stone cover
2 cannot be fitted.
Place the sharpening stone cover 2 back in
position and screw it in place with the four
screws
3 .
Q
Maintenance and cleaning
Apart from replacing the sharpening stone, the drill
sharpener is maintenance-free.
Regularly clean the device straight after using it.
To clean the casing, use a dry cloth; on no
account should you use any petrol, solvents or
cleaning agents.
Never open the devices. Any
repairs or replacements should only be carried
out by the service centre or an electrician.
Q Service
Have your device repaired
at the service centre or by qualified
specialist personnel using original
manufacturer parts only. This will ensure
that your device remains safe to use.
If the plug or lead needs
to be replaced, always have the
replacement carried out by the manu-
facturer or its service centre. This will
ensure that your device remains safe to use.
Q Warranty
The warranty for this appliance is for 3
years from the date of purchase. The ap-
pliance has been manufactured with care
and meticulously examined before deliv-
ery. Please retain your receipt as proof of
purchase. In the event of a warranty claim,
please make contact by telephone with our
Service Department. Only in this way can a
post-free despatch for your goods be assured.
The warranty covers only claims for material and
maufacturing defects, but not for transport damage,
for wearing parts or for damage to fragile compo-
nents, e.g. buttons or batteries. This product is for pri-
vate use only and is not intended for commercial use.
The warranty is void in the case of abusive and im-
proper handling, use of force and internal tamper-
ing not carried out by our authorized service branch.
Your statutory rights are not restricted in any way
by this warranty.
The warranty period will not be extended by repairs
made unter warranty. This applies also to replaced
