5
CY IE GB
General description
The illustration of the principal
functioning parts can be found on
the front and back foldout pages.
Delivery Contents
Unpack the equipment and check that it is
complete.
The equipment is supplied with the motor
head on (see 3). To take off the motor
head and remove the accessories, release
the locking lever ( 14) and fold
down the bow handle tie bars ( 2) to-
wards the suction nozzle ( 8).
- Motor housing
- Stainless steel container
- Bow handle
- Cable holder
- 4 steering castors with attachment
ports for accessories
- Telescopic suction pipe
- Suction hose
- Handle with air regulation
- Foam filter
- Fluted filter with filter cover
(already mounted)
- Paper filter bag
- Switchable household nozzle
- Crevice nozzle
- 8 cross-head screws
- Instruction Manual
Dispose of the packaging material in a
proper manner.
Overview
Housing
1 Bow handle
2 Bow handle tie bars
3 Motor housing
4 Cable holder
5 Mains power cable
6 On/off switch
7 Vent holes
8 Suction connection
9 Stainless steel container
10 Drainage outlet
11 4 steering castors
12 Anti-static chain (not visible)
13 4 attachment ports for accessories
14 Locking lever
15 Blow connection
16 2 attachment ports
17 Telescopic suction pipe
Accessories
18 Vacuum tube holder
19 Suction hose
20 Handle with air regulation
Filter
21 Foam filter for wet vacuuming
22 Filter cover
23 Fluted filter for dry vacuuming
24 Paper filter bag for vacuuming
both large and small dirt particles
Nozzles
25 Switchable household nozzle
for vacuuming carpets
for vacuuming smooth surfaces
26 Crevice nozzle
27 Filter basket
