Parkside PNTS 1400 C1 - Handbuch (Seite 9)

9
CY IE GB
Vacuuming with the dry filter
(filter bag, optionally available):
The anti-tear filter bag, which is optionally
available (see “Replacement parts / Ac-
cessories”), is suitable for vacuuming both
large and small dirt particles.
1. Place the foam filter ( 21) on the filter
basket ( 27) (see “Wet Vacuuming”).
2. Pull the fabric bag over the filter basket.
Wet vacuuming
For wet vacuuming or to vacuum water, fit
the foam filter (21) to the filter basket (27)
on the motor head (3).
To avoid tearing the foam filter (21):
- Use only a dry filter;
- Turn over the edge of the filter a little.
When the container ( 9) is full, the
suction opening is shut off by a float,
and suction is then cut off. Switch the
appliance off, remove the plug from
the socket and empty the container
(see “Cleaning/Maintenance”).
If foam or liquid exits, switch off the
machine immediately.
Blow Function
Operation without the use of a filter
is recommended.
• Connect the suction hose (19) to the
connecting blower (15) on the motor
head (3).
Cleaning/Maintenance
Pull out the mains plug.
Danger of electric shock.
Always check the appliance before
use for any obvious faults such as
a defective mains cable, and have
these repaired or replaced.
Cleaning the device:
Never hose the device down with
water. Never use aggressive cleaning
agents or solvents. This could dam-
age the appliance.
• After use, empty the stainless steel con-
tainer ( 9):
- Opening the drain plug to allow the
vacuumed liquid to drain out (
10). A liquid residue remains in the
container.
To remove all residual liquids, fold
down the bow handle (1) and take
off the motor head ( 3): fix the
bow handle with the locking levers
(14), hold the stainless steel con-
tainer (9) with one hand on the bow
handle and the other on the bottom
of the container and pour out the
residual liquid.
• Clean the waste tank with a damp cloth.
• Wash the foam filter ( 21) with luke-
warm water and soap, and allow to dry.
• Beat the dust out of the fluted filter
( 23) and clean it with a paint brush
or hand brush.
• Replace the paper filter bag ( 24)
when full (see “Replacement parts/Ac-
cessories” for reordering)
• Knock the optional dry filter (fabric bag)
out. Where necessary, wash with luke-
warm water and soap, and allow to dry.
