8
GB IE CY
bow handle tie bars (2) and screw it in
place with 2 crosshead bolts (1a).
3. Fold down the bow handle (1) towards
the suction nozzle (8). Place the motor
head (3) on the stainless steel contain-
er (9). Close the stainless steel contain-
er by folding up the bow handle and
fixing it with the locking levers (14)
(the tension can be adjusted
with the locking lever adjusting screw).
Several positions are possible for the
bow handle.
Never vacuum without a filter!
4. Fit the power cable holder (4) onto the
motor head (3) and screw it in place
with 2 crosshead bolts (4a).
5. Fit the accessories:
- Connect the suction hose (19).
- Fit the handle (20)
- Fit the telescopic suction pipe (17).
(Press the knob on the telescopic
suction pipe in the direction and
separate to the desired length).
- Fit the desired nozzle (25/26).
To store the suction set during
breaks, push together the telescopic
suction hose (17) and plug the suc-
tion pipe holder (18) into the socket
on the motor housing (see picture
below).
Operation
Switching on/off
Connect the mains plug.
Do not vacuum without a filter!
(How to insert the filter is described
in the chapters “dry vacuuming“
and “wet vacuuming“).
Switching On:
On/Off Switch (see 6) In position “I“
Switching Off:
On/Off Switch (see 6) In position “0”
Dry vacuuming
Vacuuming with a fluted filter:
1. For dry vacuuming, fit the fluted filter
(23) onto the filter basket (27) on the
motor head (3). The sealing lip that
curves upward must point away from
the motor head.
2. Fit the filter cover (22) and lock it with
a light turn:
Lock the filter cover
Unlock the filter cover
Vacuuming with the paper filter
bag:
To avoid the fluted filter becoming
clogged, we recommend the addi-
tional use of a paper filter bag.
1. Fit the fluted filter (23).
2. Fold the side flaps on the paper filter
bag (24) down on the perforation.
3. Completely unfold the paper filter bag
(24) and pull it over the internal suc-
tion nozzle (8) in the stainless steel
container (9). The connector on the
suction nozzle must be completely en-
closed by the sealing ring on the filter
bag opening.
A fine dirt filter bag made of micro
filter fleece is also optionally avail-
able, which can be used in place
of the included paper filter bag (see
“Replacement parts/Accessories”).
