The manufacturer will not be held respon-
sible for injuries resulting from use which
does not comply with the directions, or
from incorrect use.
General description
See the front fold-out page for
illustrations.
Delivery Contents
Unpack the equipment and check that it is
complete.
Dispose of the packaging material in a
proper manner.
5 Container lid incl. motor hous-
ing
10 Metal container
11 Metal suction hose
12 Suction tube
13 Pleated filter (already mounted)
14 Metal filter cage
(already mounted)
15 Pre-filter
- Instruction Manual
Description of operation
The ash vacuum cleaner is fitted with a
stable metal container with a cover. The
vacuum set comprises a flexible metal suc-
tion hose and an aluminium suction hose.
The pre-filter protects the metal filter cage
against contamination and thus, facilitates
cleaning. A safety stop prevents the vac-
uum cleaner from being operated without
the filter or filter basket.
A single-use thermal fuse permanently
disconnects the power circuit in event of
overheating or fire inside the device.
The following describes the function of the
operating parts.
Overview
1 Power cord
2 Suction tube holder
3 Inspection window blockage
indicator
4a Carry handle
4b Retaining bracket for hose and
power cord
5 Container lid
6 On/off switch
7 Hose connection
8 Seal clips
9 Arched handle for metal con-
tainer
10 Metal container
11 Metal suction hose
12 Suction tube
13 Pleated filter
14 Metal filter cage
15 Pre-filter
15a Lip seal on pre-filter
16a Safety stop pleated filter
16b Safety stop metal filter cage
17 Metal lugs for fastening the
metal filter cage
18 Air filter
19 Filter housing
20 Motor housing
