Parkside PAS 500 D3 - Handbuch (Seite 6)

6
GB IE CY
Technical data
Ash vacuum cleaner .....PAS 500 D3
Mains voltage ........... 230-240 V~, 50 Hz
Rated power input
(Power consumption) .................... 500 W
Power cord length ......................... 2.5 m
Safety class ...................................... II
Protection category.......................... IP20
Suction force ......... 12.5 kPA, (125 mbar)
Metal container capacity, brutto ........ 18 l
Length of the metal
suction hose ...................approx. 120 cm
Suction tube
Length ..........................approx. 30 cm
Diameter ......................approx. 40 mm
Weight (incl. all
accessories) ..................... approx. 4.0 kg
Technical and visual modifications may
be carried out due to further development
without prior notice. All dimensions, infor-
mation and statements provided in these
Operating Instructions are therefore subject
to amendment. Legal claims which are
based on the Operating Instructions can
therefore not be recognised.
Safety information
Device symbols
Warning!
Read carefully before use.
Retain for reference.
Do not expose the unit to rain.
For cold ashes only*!
Matter exceeding a temperature
of 40°C (104°F) poses a fire risk!
* “Cold ashes” are ashes that have cooled for
a sufficient time and no longer contain pockets
of embers. This can be determined by sifting
through the ashes with a metal implement before
using the equipment. The cold ashes emit no fur-
ther perceptible heat radiation.
1 Do not vacuum up soot or combusti-
ble materials.
During vacuuming, constantly check
the hoses and vacuum for heating.
The vacuumed material must not
exceed a temperature of 40°C
(104°F).
2 - 4 Open, empty and clean the vacuum
outdoors before and after vacuum-
ing.
Electrical machines do not belong
with domestic waste.
Safety class II
