Parkside PFBS 160 A1 - Handbuch (Seite 13)

13 GB/IE/CY
General power tool safety warnings / Start-up Start-up
Use the combination wrench 33 to tighten the
screw on the clamping mandrel.
Bricks
Firmly secure the whetstone! Use a vice or equiv-
alent tool to prevent injuries.
When using the bricks for the first time, they must
first be trimmed using the prismatic whetstone.
To do so, slowly bring the brick
23 to the whet-
stone with the tool switched on. Grinding the two
abrasive wheels together will remove uneven
areas in the contour of the brick. The whetstone
can further be used to shape the brick.
Installing sanding belts
Slide the grinding belt 24 onto the grinding
mandrel 34 from the top. Tighten the screw on
the grinding mandrel 34 to secure the grinding
belt 24 .
Attaching polishing tools
Screw the polishing tool 22 into the tip of the
mandrel for polishing attachments 25 .
Switching on and off / Adjusting
the speed
Switching on / adjusting the speed:
Set the ON / OFF switch 1 to position „I“ by
pressing down and sliding it forward.
Set the variable speed control 10 to a position
between „1“ and „6“.
Switching off:
Set the ON / OFF switch 1 to position „0“.
Information about processing
materials / tool / speed range
Use the router bits to process steel and iron at
maximum speed.
Determine the speed range for processing zinc,
zinc alloys, aluminium, copper and lead by
testing scrap pieces.
Process plastics and materials with a low melt-
ing point at a low speed.
Process wood at high speeds.
Clean, polish and buff at a medium speed.
The following information are non-binding recom-
mendations. When performing the actual work also
test yourself, which tools and settings are ideal for
the material you are working on.
