14 GB/IE/CY
Start-up
Examples of use / selecting the correct tool
Function Accessory Application
Drilling Drill bit 28 Wood applications (see Fig. C)
Milling Milling bit 27 Various applications; e.g. recessing, hollowing
out, shaping, grooving, or making slots
Engraving Engraving bits 26 Marking (see Fig. D)
Polishing, rust
removal
CAUTION!
Only apply the tool
to the work piece
under light pressure.
Metal brush 31 Rust removal (see Fig. E)
Polishing tools 22 Processing various metals and plastics, particularly
precious metals such as gold or silver (see Fig. F)
Cleaning Plastic brushes 30 e.g. cleaning hard to reach plastic housings or
cleaning the area around a door lock
Metal brush 31 e.g. rust removal (see Fig. E)
(The metal brush is softer than steel)
Grinding Grinding discs 19 , 21
Grinding stone 23 ,
Grinding bits 20
Grinding stone, detail work on hard materials such
as ceramics or alloy steel (see Fig. G)
Sanding belts 24 Sanding wood
Cutting Cutting discs 18 Processing metal, plastic (see Fig. H)
Flexible shaft
Never use the spindle lock with the motor on.
The tool or the flexible shaft could otherwise
be damaged.
Unscrew the union nut 5 from the tool, turning
counter-clockwise, and put aside.
Press and hold the spindle lock 8 .
Unscrew the clamping nut 6 from the tool,
turning counter-clockwise.
Attach the flexible shaft to the tool, inserting the
inner axle on the flexible shaft along with the
clamping nut
6 into the collet 7 .
First tighten the clamping nut 6 , then the union
nut 13 b of the flexible shaft 13 to the tool, turn-
ing clockwise.
Now insert the accessory you wish to use into
the collet
7 of the flexible shaft.
To lock the spindle, slide back the black sleeve
on the flexible shaft.
Using the combination wrench 33 , open the
collet holder 14 on the flexible shaft, insert the
accessory and tighten the collet holder 14 .
Stretch stand for the multi-
function tool (Fig. I)
Screw the stretch stand 16 into the clamp 17 .
Note: The stretch stand 16 can be screwed
into the clamp in two different positions, de-
pending on the whether you‘re attaching to a
horizontal or vertical surface.
Secure the clamp 17 at the edge of a work-
bench or a work table no thicker than 55 mm.
Start-up / Cleaning, care and storage / Warranty
