15 GB/IE/CY
Start-up Start-up / Cleaning, care and storage / Warranty
The stretch stand 16 is height adjustable. Loosen
the upper tube of the stretch stand 16 by turning
to the left (–). Extend the tube to the maximum
height and secure by turning to the right (+).
The holder 15 is also height adjustable, simple
turn the black thread to the left. After adjusting
the holder to the correct height, turn the thread
in the opposite direction to tighten.
Secure the tool to the holder 15 of the stretch
stand 16 . This holder 15 rotates by 360°.
Base assembly
Using the attachment, the tool is particularly suited
for cutting special shapes (holes for sockets, etc.).
Attach the milling bit 27 as described in chapter
„Attaching / changing the tool / collet“.
Unscrew the union nut from the tool, turning
clockwise, and put aside.
Screw the base 12 onto the unit.
To set the correct working depth, loosen the
locking screw
11 and adjust the bottom of the
base assembly to the desired size.
Then tighten the locking screw 11 .
Cleaning, care and storage
RISK OF INJURY! Switch the
tool off and pull the plug out of the mains socket
before carrying out any work on the tool.
Always keep the tool clean, dry and free of oil
or grease.
Use a dry cloth to clean the housing.
If the connection cable needs to
be replaced, this repair must be performed by
the manufacturer or a representative to prevent
safety hazards.
Carefully store the tool and all parts in desig-
nated plastic case to prevent losing any parts.
Warranty
The warranty for this appliance is for 3
years from the date of purchase. The ap-
pliance has been manufactured with care
and meticulously examined before deliv-
ery. Please retain your receipt as proof
of purchase. In the event of a warranty
claim, please make contact by telephone
with our Service Department. Only in this
way can a post-free despatch for your
goods be assured.
The warranty covers only claims for material and
maufacturing defects, but not for transport damage,
for wearing parts or for damage to fragile compo-
nents, e.g. buttons or batteries. This product is for pri-
vate use only and is not intended for commercial use.
The warranty is void in the case of abusive and im-
proper handling, use of force and internal tampering
not carried out by our authorized service branch. Your
statutory rights are not restricted in any way by this
warranty.
The warranty period will not be extended by repairs
made unter warranty. This applies also to replaced
and repaired parts. Any damage and defects extant
on purchase must be reported immediately after
unpacking the appliance, at the latest, two days after
the purchase date. Repairs made after the expiration
of the warranty period are subject to payment.
GB
Service Great Britain
Tel.:
0871 5000 720
(0,10 GBP / Min.)
e-mail: [email protected]
IAN 96078
