9
IE CY GB
• Make sure that the mains voltage cor-
responds with the information on the
rating plate.
• Only plug the appliance into a socket
which is safeguarded by at least 16 A.
• The device must only be connected to
a mains socket via a residual-current
circuit breaker (RCD) with a rated leak-
age current of not more than 30 mA.
CAUTION! The following states
how damage to the appliance and
possible injury to people can be
avoided:
• Ensure that the machine is correctly
assembled and the filters are in the cor-
rect position.
• Do not use without the filter. This could
damage the machine.
• Only use replacement parts and acces-
sories delivered and recommended by
our Service Centre (see page 16). The
use of parts by other manufacturers im-
mediately renders the guarantee void.
• Only have repairs carried out at our
authorised customer service points.
• Observe the instructions for cleaning
and maintenance of the machine.
• Store the appliance in a dry place and
out of reach of children.
Assembly
Pull out the mains plug.
Danger of electric shock.
1. Attach the feet (6) to the housing:
- The feet with wheels (6a) num-
bered  + ‚ must be fitted
into the appropriate adaptors
on the rear side of the waste
collector (see small picture).
- The feet with guide rollers
(6b) must be fitted to the hold-
ers on the front side of the
container (5).
2. Secure the feet with the Philips
head screws supplied.
3. Place the motor housing (3) on
top of the collector (5) and close
it with the clip.
4. Lightly squeeze together the
ends of the retaining bracket
(25) and click it into the motor
housing (3).
5. Installing the accessories:
- Attach the vacuum hose (18).
- Fit the handle with air control
(15).
- Install the telescopic suction
tube (16). (Press the button on
the telescopic suction pipe to-
wards and pull out to the
desired length).
- Install the nozzle desired (
21/22/23/24).
Never vacuum without a
filter!
Operation
Fully unwind the suction hose (
18) before commencing work.
Switching on/off
Connect the mains plug.
To vacuum dust, plug the electrical
tool onto the mains socket on the
vacuum ( 9).
Only connect electrical appliances
with a maximum power rating of
1400 W.
