Figure and Figure show
how to fit the spark protection and
workpiece support on the left-hand
side of the device. Fit the second
spark protection and the second
workpiece support
Assemble/adjust spark
protection
You will need a screwdriver and a
spanner (size 8 mm) to use as a coun-
ter holder to fit the above.
1. Screw the spark protection (1) to
the spark protection holder (2). To
do this, use the fixing screws (4),
nut (4a), spring washer (4b) and
washer (4c) supplied.
2. Fit the second spark protection in
a similar manner.
3. Screw the spark protection holder
(1) firmly to the protective hood
(5). To do this, use the 2 adjus-
ting screws incl. spring washers
and washers (3) and 2 nuts (3a).
4. Adjust the spark protection (1)
with the adjusting screws (3) - the
distance between the grinding
disc (10) and the spark protec-
tion must be max. 2 mm (see
small image).
Periodically readjust the spark pro-
tection in order to offset the wear
and tear of the grinding disc (dis-
tance max. 2 mm).
Despite the spark protection, you
should always wear protective gog-
gles when working in order to avoid
eye injuries.
Assemble/set workpiece
supports
1. Screw the workpiece supports
(11) on to the device.
2. To do this, use the screw (12a),
washer (12b), toothed washer
(12c) and star nut (12) supplied.
3. Set the workpiece support (11)
of the grinding disc with the star
grip nut (12) so that the distance
between the grinding disc (10)
and the workpiece support is
max. 2 mm (see small image).
Periodically readjust the workpiece
support in order to offset the wear
and tear of the grinding disc (dis-
tance max. 2 mm).
Screw device on to work-
bench
Screw the device onto the work-
bench with 4 screws and nuts.
Insert the screws through the 4 bore
holes (13) on the base of the de-
vice.
The screws and nuts required for as-
sembly are not part of the scope of
delivery.
Operation
Caution! Risk of injury!
- Always disconnect the plug from
the mains socket before working.
- Use only grinding discs and acces-
sories recommended by the manu-
facturer. The use of other insertion
tools and other accessories may
cause risk of injury.
