GB IE CY
Change grinding disc
Information on replace-
ment:
• Never operate the device without
protective equipment.
• Ensure that the rotation speed
stated on the grinding disc (
10) is the same or higher than
the nominal rotation speed of the
device.
• Ensure that the grinding disc
dimensions match those of the
device.
• Only use flawless grinding discs
(sound test: an undamaged grind-
ing disc hanging freely on a
string will result in a clear sound
if it is tapped with a plastic ham-
mer).
• Never re-drill a locating hole
which is too small to make it
larger.
• Never use separate bushings or
adapters in order to make grind-
ing discs whose hole is too large
fit the device.
• Do not use any saw blades.
• To clamp the grinding tools only
use the clamping flange provid-
ed. The pads between the clamp-
ing flange and the grinding tools
must be made of elastic materials
e.g., rubber, soft cardboard etc.
• Always reassemble the device
completely after replacing the
grinding disc.
Switch the device off and remove
the mains plug.
Allow the device to cool down.
Wear protective gloves when
changing the grinding discs in or-
der to avoid cutting damages.
The grinding disc nuts (10a) have
different threads (left-hand and
right-hand threads). To avoid dam-
aging the grinding disc spindle
thread (15), never mix up the two
grinding disc nuts (10a).
1. Undo the fixing screws ( 7) and
remove the left-hand and right-
hand grinding disc cover ( 8).
2. Unscrew the grinding disc nuts
(10a) by counter-holding the nut
on the opposite grinding disc with
a spanner (size 19 mm).
Unscrewing the left-hand nut (left-
hand thread):
turn clockwise.
Unscrewing the right-hand nut
(right-hand thread):
turn anticlockwise.
3. Remove the clamping flange (10b)
and the grinding disc (10).
4. Set up the new grinding disc (10)
with the intermediate shims (10c)
made of cardboard and the clam-
ping flange (10b) and manually
screw the grinding disc nut (10a)
on.
Screwing the left-hand nut (left-
hand thread) on:
turn anticlockwise.
Screwing the right-hand nut (right-
hand thread) on:
turn clockwise.
5. Screw the left hand and right
hand grinding disc covers (8) on.
6. Adjust the spark protection ( 1)
and the workpiece support (
11) - the distance to the grinding
