Parkside PDOS 200 B2 - Handbuch (Seite 6)

6
GB IE CY
Technical specifications
Nominal input voltage ......230 V~, 50 Hz
Power consumption ..................... 200 W
(S2 30 min)*
Safety class .......................................... I
Mechanical rating .......................... IP 20
Measurement idling speed n
0
... 2950 min -1
Velocity v
0
.......................... max. 23 m/s
Grinding disc
Outer diameter ................... Ø 150 mm
Bore hole .......................... Ø 12.7 mm
Thickness .................................20 mm
Hardness ....................................... P5
Grain size ................................36/80
Speed n0 ...................max. 4500 rpm -1
Working speed ................ max. 35 m/s
Weight (incl. accessories) .. approx. 5.7 kg
Sound pressure level
(L
pA
) ...................80 dB(A); K
pA
=3 dB(A)
Sound power level (L
wA
)
measured ...........93 dB(A); K
wA
=3 dB(A)
Vibration total value (a
h
) ......... 2,5 m/s 2
* A break is introduced after 30 minutes of
uninterrupted operating duration until the de-
vice temperature differs 2 K (2°C) less than
room temperature.
Noise and vibration values have been
determined according to the standards and
regulations mentioned in the declaration of
conformity.
Technical and optical changes may be
undertaken in the course of further develop-
ment without notice. All dimensions, refer-
ences and information in this instruction
manual are therefore not guaranteed. Legal
claims made on the basis of the instruction
manual can therefore not be considered as
valid.
The stated vibration emission value was
measured in accordance with a standard
testing procedure and may be used to com-
pare one power tool to another.
The stated vibration emission value may
also be used for a preliminary exposure
assessment.
Warning!
The vibration emission value may
differ during actual use of the
power tool from the stated value
depending on the manner in which
the power tool is used.
Safety precautions aimed at protect-
ing the user should be based on
estimated exposure under actual
usage conditions (all parts of the
operating cycle are to be consid-
ered, including, for example, times
during which the power tool is
turned off and times when the tool
is turned on but is running idle).
Safety Instructions
WARNING!
When using power tools, observe
the following basic safety measures
for the prevention of electric shocks
and the risk of injury and fire.
Please read all these instructions
before using the electric tools and
please keep the safety instructions.
