13
CY IE GB
Operation
1. Direction switch
You can toggle between right and left ro-
tation by pushing the direction of rotation
switch ( 3).
If you move the direction switch ( 3) to
the middle position, the device is secured
against being switched on. You can con-
tinue using the LED lamp when the switch
lock is activated. To do so, press the on/
off switch.
The direction changed may
only be performed in stand-
still mode!
2. Using the tool holder
Pull the locking sleeve ( 2) forward and
push the bit insert as far as it will go into the
tool holder ( 1). Release the locking sleeve
( 2) again; the bit insert is fixed in place.
Check that the bit insert is locked in the tool
holder by pulling on it.
The tool holder is not suitable
for short 25 mm bits! Use the
bit holder ( 15) supplied for
short bits.
3. Switching on/off
By using the on/off switch ( 12) you can
progressively control the speed. The LED
work light ( 13) is automatically turned on.
The further you push the on/off switch, the
higher the speed and tightening torque.
To turn it off, release the on-off button.
When you move the direction switch ( 3)
to the middle position, the device is secured
against being switched on. In this position,
the LED work light (13) can still be used.
The tightening torque depends on the se-
lected speed and impact duration.
The tightening torque actual-
ly achieved must be checked
in all cases with a torque
wrench !
Cleaning and
maintenance
Contact our Service Centre about
repairs and servicing not described
in this manual. Only use OEM
parts. Risk of injury!
Turn off the appliance and, before
doing any servicing, remove the
battery.
The following cleaning and servicing
should be done regularly. This will ensure
a long and reliable service life.
Cleaning
Do not spray the appliance
with water and do not im-
merse it in water. Electric
shock hazard!
• Keep clean the ventilation slots, motor
housing and handles of the appliance.
Use a damp cloth or a brush.
Do not use cleaning agents or solvents.
You may otherwise irreparably dam-
age the appliance.
