5
CY IE GB
General description
Extent of the delivery
Carefully unpack the appliance and check
that it is complete:
- Cordless impact screwdriver
- Belt clip with screw
- Battery-charger
- Battery
- Bit holder
- Adapter for 1/4“ square
- Translation of the original instructions for
use
The illustrations are on the
front fold-out page.
Overview
1 Tool holder
2 Locking sleeve
3 Direction of rotation switch
4 Belt clip
5 Battery Indicator
6 Charger power supply cord
7 Charger
8 Green LED
9 Red LED
10 Battery
11 Battery release button
12 On/off switch
13 LED working light
14 Adapter for 1/4“ square
15 Bit holder
Functional description
The cordless impact screwdriver has clock-
wise/anticlockwise rotation, a 1/4“
hexagon socket bit holder and an LED
work light.
The rotary impact function of the device
converts the force of the motor into uniform
rotary impacts. The striking mechanism
switches on when tightening and loosening
materials.
The battery included in the scope of de-
livery can also be used for the cordless
reciprocating saw PSSA 18 A1 and the
cordless angular grinder
PWSA 18 A1.
Technical data
Appliance
Motor voltage...........................18 V
Idling speed .....................0-2800 min -1
Nominal impact rate .........0-3600 min -1
max. torque for hard screw-driving
applications according to ISO 5393
............................................ 180 Nm
Tool holder ...................................1/4“
Weight (without battery charger) 1.54 kg
Sound power level
(L
pA
) ............. 68.72 dB (A),
K
pA
= 3 dB
Sound power level (L
W
A
)
Guaranteed ...................... 83 dB (A)
Measured ......79.72 dB (A);
K
WA
= 3 dB
Vibration (a
h
) ... 2.455 m/s 2 , K= 1.5 m/s 2
Battery (Li-Ion) ............PAP18-1,5A1
Number of battery cells ..................... 5
Nominal voltage .......................18 V
Capacity .................................. 1,5 Ah
Charging time .......................... ca. 1 h
