5
GB IE CY
are permitted to use the equipment only
under supervision.
The manufacturer shall not be liable for
damages caused by use other than for the
intended purpose or by incorrect opera-
tion.
General description
The illustrations can be found
on the front and rear fold-out
pages.
Scope of delivery
Unpack the equipment and check that it is
complete. Dispose of the packaging mate-
rial correctly.
- Chain sharpener with grinding disk
installed
- Handle
- Chain clamping unit and locking screw
- Adjusting screw and washer
- Two screws, nuts and washers for
mounting on the worktop
- Instruction Manual
Function description
Prior to first starting the appliance, firmly
mount it on a worktop. It is driven by an
electric motor with protection against over-
heating and restart for added safety.
The rake angle is easily adjustable be-
tween -30° and +30° using a rotary
disk. The chain guide rail has a variably
adjustable stopper. To sharpen, swivel the
grinding head. The equipment is fitted with
a protective screen in order to protect the
user.
For the function of the operating parts,
please refer to the descriptions below.
Summary
1 On / off switch
1a On switch
1b Off switch
2 Grinding head
3 Grinding disk cover
4 Handle
5 Fixing screws for grinding disk
cover
6 Adjusting screw and adjusting
nut for depth stopper
7 Guide rail
8 Grinding plinth
9 Stop notches
10 Locking screw for chain clamping
unit
11 Scale for rake angle (+30° to -30°)
12 Chain clamping unit and rotary
disk
13 Chain tensioning and clamping
lever
14 Chain feed adjusting screw and
adjusting nut
15 Stopper
16 Cable hook (not shown)
17 Mains cable
18 Grinding disk and grinding disk
nut (not shown)
19 LED-lamp (not shown)
20 Protective screen
21 Ventilation openings (not shown)
22 Worktop
23 2 screws (for mounting on the
worktop)
24 2 nuts (for mounting on the work-
top)
25 Washer (for adjusting screw)
26 Mounting nut (for adjusting screw)
27 Cutting tooth (chain saw)
28 Depth limiter lug (chain saw)
