Technical specifications
Chain sharpener ............FSG 85 B1
Nominal input voltage ........ 230 V~, 50 Hz
Power consumption ............... max. 85 W
(S2: 15 min)**
Rated resting period ...........approx. 5 min
Safety class ..................................... II
Mechanical rating .......................... IP 20
Idle-running speed n
0
................5000 min -1
Disk speed ....................... max. 40 m/s*
Adjustment angle .............. 30° left / right
For saw chains
with link sizes ... 6,35 / 8,255 / 9,52 mm
(1/4“ / 0,325“ / 3/8“)
Dimensions grinding disk
external diameter ...................Ø 104 mm
diameter of bore ......................Ø 22 mm
thickness .................................3.2 mm
Weight (incl. accessories) .. approx. 2.6 kg
Sound pressure level
(L
pA
) .....................83 dB(A); K
pA
=3 dB(A)
Sound power level (L
wA
)
measured ............96 dB(A); K
wA
=3 dB(A)
guaranteed ...........................99 dB(A)
Vibration (a
n
) .........3.05 m/s 2, K=1.5 m/s 2
* The grinding disk must be able to withstand
a circulation speed of 40 m/s.
** Do not operate the equipment for longer
than 15 minutes without interruption; then
take a rest break of 5 minutes.
The stated vibration emission value was
measured in accordance with a standard
testing procedure and may be used to com-
pare one power tool to another.
The stated vibration emission value may
also be used for a preliminary exposure
assessment.
Warning:
The vibration emission value may
differ during actual use of the
power tool from the stated value
depending on the manner in which
the power tool is used.
Safety precautions aimed at protect-
ing the user should be based on
estimated exposure under actual
usage conditions (all parts of the
operating cycle are to be consid-
ered, including, for example, times
during which the power tool is
turned off and times when the tool
is turned on but is running idle).
Technical and optical changes may be
undertaken in the course of further devel-
opment without notice. All dimensions,
references and information in this instruc-
tion manual are therefore not guaranteed.
Legal claims made on the basis of the
instruction manual can therefore not be
considered as valid.
