Safety advice
RISK OF FATAL
INJURY AND ACCIDENTS FOR
INFANTS AND SMALL CHIL-
DREN! Never leave children unsupervised with
the packaging materials. Danger of suffocation.
Keep out of the reach of children. It is not a toy.
BEWARE OF ELECTRIC SHOCK!
Any leaks or the escape of water can
lead to danger to life from electric
shock. Carefully check that all connections are
watertight. Also ensure that all wires of electric
appliances are correct and have been securely
installed.
CAUTION! RISK OF INJURY! Please ensure
that no parts are damaged and that all parts
are correctly assembled. Incorrect assembly
could lead to injury. Please note that washers
and gaskets are wear parts and therefore will
need to be replaced from time to time. Dam-
aged parts could adversely affect safety and
proper function.
CAUTION! Ensure that the hot / cold water
plaque
17 has been attached the right way
round. The correct position is: left = red (hot
water), right = blue (cold water).
ATTENTION! DANGER OF MATERIAL
DAMAGE! Installation may only be carried
out by experts. Leakage or escape of water can
cause significant damage to buildings and house-
hold contents. All connections must therefore be
checked carefully to ensure that they are tight.
Ensure that all seals are correctly seated to
avoid escape of water due to leakage.
Familiarise yourself with all local conditions, e.g.
water connections and shut-off device, prior to
installation.
We recommend the installation of a filter or an
angle valve. In this way you will protect the
entrance of the taps from foreign bodies and
protect the cartridge
21 from damage.
The product is intended to be only used in
rooms with a temperature above 0 °C. In case
of potential frost, cut off the water supply and
drain the taps.
Assembly
Note: Familiarise yourself with the product prior to
assembly. Carefully read the following assembly
instructions and safety advice. In the event of incor-
rect installation, all warranty claims – particularly
in relation to subsequent damage – are excluded.
CAUTION! Before you start installation turn
off the water supply at the mains. Otherwise
there is a danger of injury and / or damage to
the product.
CAUTION! Do not twist the connection hoses
10 , 12 or place them under tension.
Note: To do this you will require a Phillips
screwdriver, a slotted screwdriver and an
open-end wrench SW 9 mm.
Follow these steps:
CAUTION! Ensure that you only tighten the
connection hoses
10 , 12 manually. Do not use
pliers or a wrench. Otherwise the product
could be damaged.
Screw the two long connection hoses 10 by
hand into the two external bores in the tap.
Screw the short connection hose 12 by hand
into the middle bore of the tap.
Insert the free end of the shower hose 5 from
the top through the tap body 2 .
Using a slotted screwdriver, screw the two thread
bolts 15 as far as they will go into the tap
body 2 and remove the two securing nuts 14 .
Lay the sealing ring 6 in the nut on the bottom
of the tap body 2 and plug this into the open-
ing on your sink.
Under the sink, first place the plastic triangle
7 , the C sealing washer 8 and then C metal
washer 9 over the threaded bolts 15 .
The screw the two locking nuts 14 onto the
thread bolts 15 and tighten then with the open-
end spanner SW 9 mm until the tap is seated
firmly on the sink.
Lay the rubber seal 3 into the union nut of the
shower hose 5 and screw the union nut onto
the thread of the rinsing spray 4 .
Lay the rubber seal 24 into the union nut 13 of
the short connection hose 12 and connect this
to the shower hose 5 .
