9 GB/IE
Replacing the cartridge
A cartridge 20 is a wear part that needs replacing
according to the hardness and / or degree of con-
tamination of the water. This becomes evident when
the handle
1 becomes difficult to move. A new
cartridges 20 can be obtained from the listed
service office.
Note: This step requires the included Allen key
(2.5 mm)
27 and an open-end spanner SW 30 mm.
Proceed as follows to replace the cartridge 20 :
Shut off the main water supply. Allow any
remaining water in the pipework to drain.
Remove the hot / cold plaque 17 by moving the
handle 1 into top-most position and pushing
the plaque out carefully from inside with a
long, flat object.
Loosen the locking screw 16 with the Allen key
27 by turning it counter-clockwise.
CAUTION! Do not unscrew the screw com-
pletely. Only loosen this as far as is necessary
to remove the handle
1 .
Remove the handle 1 .
Unscrew the cartridge covering ring 18 .
Loosen the cartridge locking ring 19 below
with an open-end spanner SW 30 mm and
remove the entire cartridge
20 from the body
of the tap 2 .
Place the new cartridge 20 (Type 40 M ESV)
into the body of the tap 2 in exactly the same
way.
Note: Make sure that the seal is fitted properly
under the cartridge
20 . Make sure that the
guides are in the corresponding holes.
Re-assemble all the afore-mentioned parts again.
Tighten the cartridge securing ring 19 whilst
holding the tap in place against the rotating
movement. This ensures tightness and prevents
the lever motion from becoming sluggish.
Disposal
The packaging is made entirely of recy-
clable materials which you can dispose
of at your local recycling facilities.
Contact your local waste disposal authority for
more details on how to dispose of the product when
it is no longer needed.
Information
Potability of tap water
Find out about the potability of your tap water
supply. Your local water authority or water
supply company will be able to inform you.
The following general recommendations apply to
the potability of tap water:
Let the water run freely for a short time if it has
been stagnating in the pipes for more than four
hours. Do not use any of this stagnant water in
the preparation of food or for drinking. This ap-
plies particularly as far as babies and infants
are concerned. Otherwise health concerns can
arise. Fresh water can be readily distinguished
from stagnant water as fresh water is noticeably
cooler as it leaves the pipe.
Do not use stagnant water from chromium-plated
pipes for the preparation of food or for drinking
or for personal hygiene if you are allergic to
nickel. This water may contain high quantities
of nickel and trigger an allergic reaction.
Do not use water from lead pipes for preparing
food or drink for babies or infants. Do not use
it for preparing food or drink during pregnancy.
Lead dissolves in drinking water and is particu-
larly damaging to the health of babies and
young children.
Warranty and Service
The warranty period is 3 years and begins on the
day of purchase. Please retain your receipt as proof
of purchase.
During the warranty period defective fittings can
be sent to the Service address given below with the
carriage costs charged forward. You will then
receive a new one or a repaired unit free of charge.
Maintenance and Cleaning / Disposal / Information / Warranty and Service
