8 GB/IE
Fasten the hose weight 25 to the shower hose
5 at the bottom of the sink in such as way that
the rinsing spray 4 can be pulled out of the
tap sufficiently and can still be held securely in
the inserted position.
Fasten the two long connection hoses 10 to the
pre-mounted seals 11 or to the angle valves, if
appropriate. Ensure that the connection to hot
and cold water is correct.
Preparations for use
After the initial commissioning, check all connections
for leakage carefully.
In order to remove any possible impurities, the tap
has to be flushed before it is used for the first time.
To do this, proceed as follows:
Unscrew the aerator 23 from the rinsing spray 4 .
Open the main water supply and allow the
water to flow for two minutes to flush out any
residues.
The replace the aerator 23 by screwing it onto
the rinsing spray again 4 .
Operation
Note: If the tap has not been used for a long
period flush the pipes through thoroughly in order
to avoid stagnation and build-up of residues.
Open the main water supply.
Lift the handle
1 and swing it to the right or
left in order to regulate the speed or temperature
of the water.
Hot water:
Swing the handle
1 to the left.
Cold water:
Swing the handle
1 to the right.
Check operation of the mixer. To do so, swing
the lever 1 into all permissible positions.
Please check the connections regularly to
ensure that they are tight.
Switch over rinsing spray
The rinsing spray head 4 is equipped with change-
over buttons 21 , 22 for the shower function.
Press the top button 22 on the show head to
activate the shower.
Press the bottom button 21 to activate the
aerator 23 .
Maintenance and Cleaning
Maintaining and
cleaning the tap
Please note that sanitary taps require special care
and attention. Therefore, please follow the instructions:
When cleaning, never use petrol, solvent, ag-
gressive cleansers or hard cleaning brushes etc.
These could damage the surface of the product.
Dry your taps with a cloth after every use in
order to avoid the build-up of any limescale.
Clean the product with a damp, soft cloth and
a mild cleaning agent if required.
Unscrew and remove the aerator 23 at regular
interval and remove any residues of scale or
foreign bodies. In case of sever contamination
or damage, replace the aerator
23 with a new
one which you can order from the Service
Centre notified to you.
Note: The aerator 23 can normally be un-
screwed by hand. Otherwise use an open-end
spanner SW 22 mm and be sure to wrap the
aerator
23 with a thin damp cloth to prevent
damaging it. A pipe wrench with plastic jaws is
also suitable.
Non-observance of the above care advice can be
expected to result in damage to the surfaces of the
product. In this event your rights under the warranty
may be invalidated.
Assembly / Preparations for use / Operation / Maintenance and Cleaning
