7 ULSP 2 A1
GB
Reference measuring mode
In this mode, you can compare the paint thicknesses on
various surfaces: for example, on one particular vehicle.
This is useful for determining diff erences in paint thicknesses.
For example, you can quickly fi nd out whether a surface has
been repainted or fi lled.
♦ When the device is in normal measuring mode, place the
measuring sensor at right angles to the surface to be
measured.
NOTE
► The best place to start is the roof of a car, which nor-
mally will not have been repainted or fi lled. The paint
coat to be measured must be thinner than 1.8 mm. The
reference measuring mode only works if the yellow or
the green LED is illuminated.
♦ Press the TEST button during the measuring process.
The measured paint thickness is now used as a reference
value. The red and green LEDs will fl ash alternately.
♦ As soon as you remove the measuring sensor from the
reference surface, the red and the yellow LEDs will fl ash
alternately.
♦ Now place the measuring sensor on the surface to
be compared: for example, the wing. The LEDs will now
fl ash in two possible combinations:
