6 ULSP 2 A1
Measuring procedure
Normal measuring mode
CAUTION
► Place the device carefully on the surface to be meas-
ured, and do not move it during measuring. Remove
the device carefully from the surface after measuring,
otherwise you could cause scratches on the paintwork.
♦ Remove the protective cap and switch the device on
(standby mode).
♦ Keep the device away from any surfaces and then press
the TEST button . The red LED will illuminate perma-
nently and the device is now in normal measuring mode.
♦ Place the measuring sensor at right angles to the
surface to be measured. The measured paint thickness
will be signalised by one of the three LEDs illuminating
(see table).
LED colour Paint thickness
Red > approx. 1.8 mm
Yellow approx. 1.0–1.8 mm
Green < approx. 1.0 mm
♦ Press the TEST button again to return to standby mode.
The red LED fl ashes.
