- 7 -
Anti-Blocking Switch (ABS)
At the start of the lamination process, the pouch
may be pulled in at an angle or jam itself inside the
appliance.
➩
Turn the anti-blocking switch (ABS) o to the
position ABS.
• The laminate pouch is not pulled any further in.
➩
Remove the laminate pouch.
➩
Turn the anti-blocking switch (ABS) o back to
the desired foil thickness.
➩
Re-start the lamination process.
Trimming function
Should you wish to use the trimming function on the
foil guide rails
q , dismantle the foil guide rails q .
➩
If necessary, fold the documents support s
down.
➩
Adjust the cutter attachment d so that it forms
a straight face with the foil guide rails q .
➩
Slide the cutting head e to the end stop (the
cutting head e can be slid to both ends of the
cutting rail w ).
➩
Flap the cutting rail w upwards with the roun-
ded grip and position the document on the foil
guide rails
q . Restrain the document by sliding
the foil format restraint r together until they
touch both sides of the document.
➩
Use the markings on the measurement table to
align the document precisely.
➩
Flap the cutting rail w downwards so that it
engages.
➩
Hold the paper in a secure position with your
left hand.
➩
To trim, press the cutting head e down with
the right hand and then slide it with one pull or
push over the document.
Cleaning and care
Potentially fatal electrical shock:
• Never open the appliance housing. There
are no user-serviceable elements inside.
• Never submerse the appliance into water
or other liquids!
Cleaning the housing:

Clean the surface of the housing with a
slightly moistened cleaning cloth.
➩
First remove the plug.
➩
Allow the appliance to cool down completely.
➩
Ensure that no moisture can permeate into the
appliance.
Cleaning the interior of the appliance:
With every lamination, contaminants are deposited on
the rollers inside the laminator. Over time, this reduces
the performance of the laminator. You should therefo-
re clean the rollers inside the laminator after use.
➩
Prepare the appliance as described in chapter
"Preparing for hot lamination", up to the point
where the green indicator lamp "Ready"
y
glows.
➩
Then run a sheet of DIN A3 paper, folded in
the middle (maximum thickness 1.0 mm) …
• without a laminating pouch and
• with the fold first
… slowly into the slot for manual pouch input t .
➩
Release the sheet as soon as you notice it
being pulled in automatically.
• The contaminants on the rollers inside the lami-
nator now firmly attach themselves to the sheet
of paper. The paper is discharged from the foil
slot
a of the laminator.
➩
Repeat this cleaning process several times.
Use a fresh clean sheet of paper each time.
When you no longer see any contaminants on the
paper, the rollers inside the laminator are clean.
