United Office ULG 300 A1 - Handbuch (Seite 8)

- 5 -
Preparing for hot lamination
➩
Insert the foil guide rails q in the designated
holes on the rear of the laminator.
➩
Fold out the document supports s , so that the
documents can be pulled in straight into the slot
for manual foil feed
t .
➩
Insert the plug of the laminator into a mains
power socket.
➩
Provide a firm location for the appliance.
➩
Set the selector switch for hot and cold lamina-
tion
i to "HOT ".
➩
Set the foil thickness switch o to the desired
foil thickness (80 or 125 microns). The red
ON/OFF indicator lamp
u will now glow.
The laminator heats itself up to its operating
temperature.
• As soon as the green indicator lamp "Ready"
y glows, the laminator has reached its
operating temperature.

Attainment of the operating temperature
is indicated by the lighting up of the green
LED indicator lamp "Ready"
y . For a
more uniform laminating result we recom-
mend, especially for thinner foils (below
125 Micron) and after adjustment to a dif-
ferent foil thickness, to first wait an addi-
tional 2-3 minutes before beginning with
lamination.
➩
Lay the document to be laminated into a lami-
nating pouch of the appropriate size.

Make certain that all corners of the docu-
ment have at least two millimetres of space
to the edge of the laminating pouch, as
shown in Fig. 1. Make certain that you use
only one pouch for laminating. First open
it up, as shown in Fig. 2.

For further information about the lami-
nation process, please read the section
"Lamination process".
Fig. 2
Fig. 1
