- 2 -
A3 Laminator
Introduction
Congratulations on the purchase of your new appli-
ance.
You have clearly decided in favour of a quality pro-
duct. These operating instructions are a part of this
product. They contain important information in regard
to safety, use and disposal. Before using the product,
familiarise yourself with all of these operating and
safety instructions. Use the product only as descri-
bed and only for the specified areas of application.
In addition, pass these documents on, together with
the product, to any future owner.
Intended use
This laminator is intended exclusively for use in priva-
te households and for the hot and cold lamination
of documents printed on paper or cardboard.
Additionally, the documents can be trimmed.
It is NOT intended for use with any other materials.
It is also NOT intended for commercial or industrial
applications.
The warranty does not provide compensation for
damage caused by improper use of the appliance!
Items supplied
1x Laminator with pluggable cutter attachment
8x DIN A3 size Laminating pouches for hot lamina-
tion (80 microns)
1x Operating instructions
Appliance description
q
Foil guide rails (rear)
w
Cutting rail
e
Cutting head
r
Foil format restraint
t
Slot for manual foil feed
y
Indicator lamp "Ready"
u
ON/OFF Indicator lamp
i
Selector switch for hot and cold lamination
(HOT and COLD)
o
Anti-blockage switch and foil thickness switch
a
Foil slot (front)
s
Document support
d
Cutter attachment
Technical Data
Rated voltage:
220 - 240 V ~, 50 Hz
Current consumption:
1.4 A
Power consumption:
300 W
Lamination speed:
Foil width:
max. 320 mm
Foil thickness hot lamination:
max. 125 Mikron
Foil thickness cold lamination:
max. 200 Mikron
Protection class:
II/
Cutting capacity of the cutter attachment
d
:
max. 3 Sheets of 80g/m
2
or a laminated document
(80 micron).
Sheet size
80 Micron
125 Micron
A4
approx. 54 s
approx. 76 s
A3
approx. 75 s
approx. 105 s
IB_96273_ULG300A1_LB6 13.12.2013 7:53 Uhr Seite 2
DIN A5 148 mm x 210 mm
