Items supplied
- Pump
- Short drive shaft
- Long drive shaft
- Clamp fixing
- Mounting
- Open-ended spanner
- Storage box for the drive shafts and open-ended spanner
- This operating manual
Overview of the appliance
q Pump
w Drive shaft of the pump
e Short drive shaft (suitable for gear-wheel/quick-release chuck)
r Long drive shaft (suitable for a drill chuck with SDS fitting)
t Clamp fastening
y Mounting
u Electric drill (not supplied)
i Recess for chuck key
o Connection for suction hose
a Connection for pressure hose
Assembly material required
- Philips-type screwdriver
- Flat-headed screwdriver
- Open-ended spanner (supplied)
