Now push the pump
q
onto the mounting
y
so that the drive shaft
e
projects into the thread of the drive shaft
w
, and the pins of the mounting
y
are located in the reception holes on the pump
q
.
Let the drill
u
start to run in a clockwise rotation and at low revolutions
and then guide the pump
q
straight onto the drive shaft
e
. The drive
shaft
e
is thereby secured to the pump
q
.
Attach the suction hose to the connection
o
and the pressure hose to the
connection
a
. Pay heed to the direction of flow
detailed on the
pump
q
.
When using a chuck with SDS fitting and the long drive
shaft r...
Attach the long drive shaft
r
into the chuck.
Insert the electric drill
u
, with the pre-assembled drive shaft
r
in the
chuck, into the mounting
y
.
Tighten the cross-headed screw on the mounting
y
firmly, so that the drill
u
cannot jolt around.
Now push the pump
q
onto the mounting
y
so that the drive shaft
r
projects into the thread of the drive shaft
w
and the pins of the mounting
y
are located in the reception holes on the pump
q
.
Allow the electric drill
u
to run with a clockwise rotation and low revoluti-
ons and guide the pump
q
straight on to the drive shaft
r
. With this the
drive shaft
r
will be fixated onto the pump
q
.
Attach the suction hose to the connection
o
and the pressure hose to the
connection
a
. Pay heed to the direction of flow
detailed on the
pump
q
.
