Disassembly of the drive shaft
Disassembly of the short drive shaft e
Wheel rim chuck
Open the chuck with the chuck key through the recess
i
and then remove
the pump
q
from the mounting
y
.
Unscrew the short drive shaft
e
by using a cross-headed screwdriver and
the open-ended spanner from the pump
q
.
Quick-release chuck
Using the open-ended spanner through the recess
i
, counter screw the
drive shaft
w
of the pump
q
.
Allow the electric drill
u
to run with an anti-clockwise rotation and low re-
volutions. The drive shaft
e
is thereby released from the pump
q
.
Remove the pump
q
from the mounting
y
.
Remove the drive shaft
e
from the chuck.
Disassembly of the long drive shaft r
Chuck with SDS fitting
Using the open-ended spanner through the recess,
i
counter screw the
drive shaft
w
of the pump
q
.
Allow the electric drill
u
to run with an anti-clockwise rotation and low
revolutions. With this the drive shaft
r
will be released from the pump
q
.
Remove the pump
q
from the mounting
y
.
Remove the drive shaft
r
from the chuck.
