Multi-Contact MA026 Benutzerhandbuch
Multi-Contact Relais
Advanced Contact Technology
www.multi-contact.com
1 / 4
Bis zur Montage möglichst staub- und feuchtigkeitsgeschützt lagern!
Where possible, store away from dust and humidity before fitting!
Nicht im MC-Lieferumfang enthalten:
Not supplied by MC:
Befestigungselement (2x) Kundenspezifisch
Customer-specific fitting (2×)
Scheibe DIN9021
DIN9021 Washer
Nutenstein
Slot nut
6kt. Schraube
DIN931 M8 8.8
DIN931 M8 8.8
hex. screw
Spannscheibe
Spring washer
20008583 = M8
20008559 = M6
MA026 (de_en)
Montageanleitung
MA026 (de_en)
Assembly instructions
MC-Erdungskontakt
Zeichnungs-Nr.: 20008583 / 20008559
MC earthing contact
Drawing No.: 20008583 / 20008559
Inhalt
Sicherheitshinweise....................................................................2
Notwendiges Werkzeug ������������������������������������������������������������3
Vorbereitung des Gegenstückes �����������������������������������������������3
Montage ������������������������������������������������������������������������������������3
Anschluss ����������������������������������������������������������������������������������4
Content
Safety Instructions ......................................................................2
Tools required ............................................................................3
Preparing the counterpart ��������������������������������������������������������3
Assembly �����������������������������������������������������������������������������������3
Connection ��������������������������������������������������������������������������������4
