Montage-Variante Nr. 5
Mouting way. Nr 5
Andere Reihenfolge der Montage für Einbaudosen
ID/...10AR-N und ID/...14AR-N.
Different way of assembly order for receptacles ID/...10AR-N
and ID/...14AR-N.
1. Selbstschneidende Schrauben M3
2. Kontakteinsatz (Stecker oder Buchse)
3. Adapter (für ID/...10AR-N)
4. Kontaktträger
5. Frontplatte
6. Gehäuse
7. U-Scheiben
8. Anschlussmutter
9. Fächerscheibe
1. Self-cutting screws M3
2. Contact insert (plug or socket)
3. Adapter (for ID/...10AR-N)
4. Contact carrier
5. Front panel
6. Housing
7. Washers
8. Connection nut
9. Serrated lock washer
