Multi-Contact MA272 - Handbuch

Advanced Contact Technology
www.multi-contact.com 1 / 8
PV-JB/LP...
PV-DJB/LP
MA272 (de_en)
Montageanleitung MA272 (de_en)
Assembly instructions
Einpolige Anschlussdose
PV-JB/LP... PV module single pole junction box
PV-JB/LP...
Inhalt
Sicherheitshinweise....................................................................2
Erforderliche Werkzeuge und Materialien .................................3
Produktansichten .......................................................................4
Montieren der Anschlussdose an das PV-Modul ......................5
Elektrischer Anschluss der Anschlussdose an das PV-Modul .....5
Anbringen der Versiegelungsmasse und des Deckels ..............6
Technische Daten der Produkte.................................................7
Content
Safety Instructions ......................................................................2
Tools / Assembly materials ........................................................3
Product overview .......................................................................4
Mounting the junction box to the PV module ...........................5
Electrically terminating the junction box to PV module ............5
Encapsulation and lid placement ..............................................6
Product specifi cation .................................................................7
