Advanced Contact Technology

Hersteller/Producer:

Multi-Contact Essen GmbH

Westendstrasse 10

DE – 45143 Essen

Tel.

+49 / 201 / 83105-0

Fax

+49 / 201 / 83105-99

mail

[email protected]

www.multi-contact.com

© b

y Multi-Contact A

G, Switz

erland – MA274 –10.2013, Inde

x c

, Global Communications – Änderungen v

orbehalten / Subject to alterations

1)

Bemessungsspannung [

V] DC

Rated voltage [

V] DC

Verwendbarer Kabeltyp

Used cable tape

Hersteller

Producer

1000

FlexSolXL

Multi-Contact

BETAFlam 125 Flex Solar

Leoni Studer AG

Byson PV-Kabel

Kunshan Byson electronics

1500

BETAFlam Solar 125 flex

UL 1000 V

Leoni Studer AG

2)

Bemessungsspannung

Rated voltage

[V] DC

Typ

Type

verwendbarer Kabeltyp

used cable type

600

PV-JB/WL-V-00-A
PV-JB/WL-V-01-A

PV Kabel des Typs BETAFLAM 125-flex SOLAR FRNC der Leoni Studer AG
PV cable type BETAFLAM 125-flex SOLAR FRNC from Leoni Studer AG

1000

PV-JB/WL-V-00-B
PV-JB/WL-V-01-B

PV Kabel des Herstellers KUNSHAN BYSON ELECTRONICS Co� Ltd�
PV Cable from KUNSHAN BYSON ELECTRONICS Co� Ltd�

1000

PV-JB/WL-V-00-D
PV-JB/WL-V-01-D

PV Kabel des Typs BETAFLAM Solar 125 flex UL 1000 V der Leoni Studer AG
PV Kabel des Typs BETAFLAM Solar 125 flex UL 1000 V der Leoni Studer AG

Technische Daten

Technical data

Typenbezeichnung

Type designation

PV-JB/WL-V

TÜV-zertifiziert nach EN 50548

TÜV certified according to EN 50548

Zertifikat / Certificate R 60085113

UL-zertifiziert nach UL 4703

UL certified according to UL 4703

Zertifikat / Certificate E 335016

Bemessungsstrom in Ampere (A)

Rated current in amperes (A)

Dioden abhängig (siehe Bypass-Diodenty-

pen)

Dependent on diodes (see bypass diode

types)

Bemessungsspannung

Rated voltage

1000V / 1500V (IEC)

1)

600V/1000V DC (UL)

2)

Bemessungsstossspannung

Rated surge voltage

8KV

Maximal zulässige Arbeitsspannung

Maximum permitted operating voltage

< 80V

Verschmutzungsgrad

Degree of pollution

2 im Gehäuse der Anschlussdose

2 in the housing of the junction box

Schutzklasse nach IEC60529

Protection class according to IEC60529

IP65

Temperaturbereich

Temperature range

-40°C... +85°C

Art der Anschlüsse

Type of connections

MC3, MC4, MC4-EVO 3

Kontaktmaterial

Contact material

Kupfer, verzinnt

Copper, tinned

Hinweis

Warning

Nicht trennen unter Last

Do not disconnect under load

Polarität der Steckverbinder

Polarity of the plug connectors

Buchse / Socket = Plus / positive

Stecker / Plug = Minus / negative

Bypass-Diodentypen

Bypass diode types

Diotec SBX 3040 12A

Vishay VSB 2045 10A
