Multi-Contact MA106 Benutzerhandbuch

6kv impulse

Advertising
background image

Advanced Contact Technology

www.multi-contact.com

1 / 8

green-y

ello

w

black

red

blue

yello

w

green

violet

bro

wn

gre

y

white

transparent

2

0

21

22

23

24

25

26

27

28

29

33

* Available colours:

LS425-SL .............. 22.1025
LS425-SL/N ........... 22.1032

FLEXI-2V/HK2,5D .....60.7033-*
FLEXI-2V/HK1-D .......60.7036-*
HK18-H ..............22.0110-001*
SILI-E2,5 ..................61.7556-*
SILI-1V1,0 ................61.7607-*

KT425-SL .............. 22.2260
KT425-SL/F ........... 50.1109

6kV IMPULSE

KT-6kV (+HK18-H) AM

22.7120

MA106 (de_en)
Montageanleitung

MA106 (de_en)
Assembly instructions

Axiale Ø 4mm Stecker
SLS425-SL, SLS425-SL/F, SLS425-SL/N,
SLS425-SL/N/F

In-line Ø 4mm plugs
SLS425-SL, SLS425-SL/F, SLS425-SL/N,
SLS425-SL/N/F

Inhalt
Sicherheitshinweise....................................................................2
Notwendiges Werkzeug ............................................................3
Vorbereitung der Leitung ...........................................................4
Montage ....................................................................................4
Notizen ......................................................................................6

Content
Safety Instructions ......................................................................2
Tools required ............................................................................3
Preparation of the cable ............................................................4
Assembly ...................................................................................4
Notes .........................................................................................6
