Notwendiges Werkzeug Tools required
(ill.1)
Abisolierzange „Stripax“
Bestell-Nr. 25.0015 (ill.1)
Cable stripper „Stripax“
Order No. 25.0015
(ill. 2)
- Lötkolben 60 W
- Lötdraht
z.B. bleifreies Lot Ø1,5#58/405
(SN95.8Ag3.5Cu.7)
ANSI/J-STD-004
Bezugsquelle:
www.kester-online.de (ill. 2)
- Soldering iron 60 W
- Solder
e.g. leadfree solder Ø 1,5#58/405
(SN95.8Ag3.5Cu.7)
ANSI/J-STD-004
Source of supply:
www.kester-online.de
(ill. 3)
Crimpzange z.B. Klauke PZK 3
Bestell-Nr. 25.0018 (ill. 3)
Crimping pliers e.g. Klauke PZK 3
Order No. 25.0018
Vorschläge für Hilfswerkzeug Suggested tools
(ill. 4)
Hilfswerkzeug A-SL Ni
Empfohlenes Material:
Messing. (ill. 4)
Auxiliary tool A-SL Ni
Recommended material: Brass.
(ill. 5)
Hilfswerkzeug B-SL Ni
Empfohlenes Material:
Stahl. (ill. 5)
Auxiliary tool B-SL Ni
Recommended material: Steel.
