Installation Manual - Solar-Log™ RS485 Wireless Package
2�3 Package contents
The Wireless Package consists of two wireless modules, two connection cables, one power supply, one
diagnostic connector and one power adapter for a nine-volt battery.
Batteries are not included.
Fig.: Package contents of the Solar-Log™ RS485 Wireless Package
2�4 Mounting
The device is produced according to protection class IP20 and is intended only for installation in interior
areas that are dry and dust-free.
•
Put the housing where it is to be fitted and mark the drill holes.
•
Drill the holes and insert the wall plugs.
•
Fasten the housing with the screws.
Important !
Before deciding a final spot to mount the Wireless module,
use the connection test to find the optimal location for signal strength.
