- 1 -
Video 60 Plus Studio
Manual
1
Safety instructions
Á
Before using the Video 60 Plus Studio fluid head make sure
that all 4 fixing screws of the tripod’s flat base are secured
tightly.
Á
When releasing the vertical brake make sure that the came-
ra is secured against any sudden movement.
Á
Do not operate the fluid head upside down without the
necessary securing devices, i.e. ropes etc.
Á
Before transport reset fluid damping to “0”.
2
Operating elements
VIDEO 60
Plus
Spindle of the Camera balance plate
Safety pin of
the V-plate lock
Vertical brake
Tilt safety lock
Horizontal brake
Vertical setting
of fluid damping
Horizontal setting
of fluid damping
Counterbalance knob
Clamp of the camera balance plate
Touch bubble
V-plate-lock
Lever for ½ counterbalance springs
Battery holder for touch bubble
Teleprompter connection
Rosette for
mounting panbar
