Product overview
Nr Description
1 Dust cover hinges (2×)
2 Platter
3 Platter mat
4 Platter bearing
5 Speed selector 33, 45
6 PHONO / LINE Switch Phono-preamp on-/off
7 RCA-Cable-Output red - right channel, white - left channel
8 DC IN: 12 V-Input for Power supply
9 Start button
10 Stop button
11 Lever record size 17, 30
12 Tonearm
13 Tonearm lift
14 Tonearm rest
15 Tonearm lift lever
16 Tonearm
17 Headshell
6 7
13
8
12
14
15
16
17
11
1
2
3
4
10 5
9
