20
Operating the turntable
Removing / Attaching the stylus protection cap
Remove the stylus protection cap from the pick-up prior to playing a record. (Pic.1)
1. Pull the cover from the stylus on the bottom (B) as seen in the diagram.
2. Replace the cap after playing the record.
To play the record (manually)
1. Place a record on the turntable; use the spindle adaptor to play singles.
2. Push the speed button for the required setting: 33, 45.
3. Raise the tonearm with the lift lever. (15)
4. Carefully move the tonearm away from the tonearm rest and position it above the first groove on the record. The motor is turned on.
5. Lower the tonearm with the lift lever. (15)
6. Playback can be stopped at any time by pressing the stop button (10), or manually, by lifting (15) and returning the tonearm.
7. The tonearm will return to the tonearm rest automatically at the end of the record and the motor will switch off.
Note:
The tonearm can be raised at any point, even for short periods. The platter will continue to turn.
To play the record (automatically) (Pic.2)
1. Place a record on the platter, use the spindle adaptor to play singles and select the record size (3).
2. Press the speed button for to the required setting of 33 or 45.
3. Press the start button (1).
4. The platter will start turning and the arm will move towards the first groove and will be lowered onto the record.
5. The operation can be stopped at any time with the STOP button (2). The tonearm will return to the tonearm rest automatically.
6. The tonearm will return to the tonearm rest automatically at the end of the record and the motor will switch off.
Note:
No automatic function for records with 25cm diameter!
The tonearm can be lifted at any time during the automatic playback process.
To set the speed
The turntable speeds can be adjusted with a small screwdriver
via two holes in the base plate.
Replacing the stylus
The stylus is naturally exposed to wear and tear by the playback process.
Therefore, we recommend regular inspections.
1. Remove the stylus by pulling diagonally downwards. (Pic. 3)
2. Insert the stylus by doing the performing the reverse action.
Note:
Worn or damaged (splintered) styluses ruin records.
When you need to replace a stylus, use the original type if possible.
Pic. 1
Pic. 2
Pic. 3
1 2
Stylus
Cover
3
